Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Unidirectional Carbon Beyond Road Platform, 1x Drivetrain Specific, 700c x 45mm/650B x 50mm Compatible, Flat Mount Disc, 142x12 Thru-Axle, Internal Dropper Post Routing, Internal Housing Routing, Mudguard and Rear Carrier Mounting, Plentiful Gear Mounts
Suspension Fork
Marin Full Carbon w/ Taper Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano GRX Shadow w/ Clutch
Front Derailleur
-
Shift Levers
Shimano GRX GX8010, 1x11-Speed, Integrated Dropper Lever
Cassette
SunRace 11-Speed XD, 10-42T
Crank
FSA Gossamer Pro, Megatooth 42T Chainring, BB386EVO Alloy Spindle
Bottom Bracket
FSA MegaExo Threaded
Chain
KMC X11
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, XD Driver, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, 21mm Tall, Disc Specific, Tubeless Compatible
Tires
Schwalbe G-One Performance, 700Cx40, Folding Bead
Brakes
Brakes
Shimano GRX Hydraulic Disc, 160mm Rotor
Brake Levers
Shimano GRX Hydraulic w/ Shifter & Integrated Dropper Lever
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Flat Top, Compact 12º Flared Drop, Flat Top
Grips
Marin Shock Absorbing Tape
Headset
FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
Seat
Saddle
Marin Beyond Road Concept Elite
Seatpost
TranzX YSP11 Dropper Post, 105mm Travel, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.51 mm | 1.55 mm | 1.55 mm | 1.5 mm | 1.49 mm |
| Bottom Bracket Height | 283.5 mm | 272 mm | 272 mm | 272 mm | 272 mm | 272 mm |
| Front Center | 602 mm | 599 mm | 599 mm | 620 mm | 651 mm | 671 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 64 mm | 67 mm | 64 mm | 63 mm | 64 mm | 64 mm |
| Stack | 556.3 mm | 571.7 mm | 587.8 mm | 606.8 mm | 625.7 mm | 644.7 mm |
| Reach | 376 mm | 378.8 mm | 378.7 mm | 392.4 mm | 417.4 mm | 431.8 mm |
| Top Tube Length | 528 mm | 541 mm | 551 mm | 571 mm | 601 mm | 621 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 1016 mm | 1013 mm | 1013 mm | 1034 mm | 1065 mm | 1085 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 717 mm | 731 mm | 747 mm | 764 mm | 781 mm | 798 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Headlands 2 is part of the Marin Headlands model. There are 12 bikes that carry this model name. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Marin Headlands 1 2020 is the cheapest bike model and costs 2399$. Marin Headlands 2 2020 is the most expensive one and costs 2849$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Marin released this model in 2020, its price was 2849$. If we compare this with the average Gravel bike cost we notice that the price is 15.72% higher.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Marin Headlands 2 2020, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Headlands 2 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Dropper post
The Marin model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
