Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Tourney -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 700C Wheels, Step Through Design, Fender and Rack Mounts
Suspension Fork
Steel, Straight Blade, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
Shimano FD-TY710
Shift Levers
Shimano EF500 8-Speed
Cassette
Sunrace 8-Speed, 11-32T
Crank
Shimano TY301, 42/34/24, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Tires
Schwalbe Road Plus, 700Cx40, Reflective Sidewall, Kevlar Puncture Protection
Brakes
Brakes
Forged Alloy Linear Pull w/ Power Modulator
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Adjustable Height & Angle
Handlebar
Marin Alloy, 30mm Rise
Grips
Marin Commute
Headset
FSA, Threaded
Seat
Saddle
Marin Women's City + Sport Extra Plush
Seatpost
Alloy Suspension Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.56 mm | 1.55 mm | 1.56 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 624 mm | 639 mm | 654 mm | 663 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 76 mm | 76 mm | 76 mm | 73 mm |
| Stack | 582.55 mm | 610.83 mm | 624.97 mm | 641.28 mm |
| Reach | 386.72 mm | 391.99 mm | 402.12 mm | 411.5 mm |
| Top Tube Length | 588 mm | 603 mm | 618 mm | 633 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 503 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 140 mm | 170 mm | 185 mm | 200 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1073 mm | 1089 mm | 1104 mm | 1113 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 526 mm | 527 mm | 529 mm | 530 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Kentfield CS2 is a Marin Kentfield model. There are 33 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fitness bikes average price
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fitness bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When leaving the production line, the Kentfield CS2 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Kentfield CS2 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
