Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Tourney -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
SM
152cm - 164cm
MD
161cm - 174cm
LG
171cm - 182cm
XL
179cm - 189cm
XXL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 City + Sport, 6061 Aluminum, 700C Wheels, Step Through Design, Fender and Rack Mounts
Suspension Fork
Steel, Straight Blade, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Altus 8-Speed
Front Derailleur
Shimano FD-TY710
Shift Levers
Shimano EF500 3x8-Speed
Cassette
SunRace 8-Speed, 11-32T
Crank
Forged aluminum, 48/38/28T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Spokes
14g Stainless Steel
Tires
Vee Tire, Zilent, 700x38, Wire Bead
Brakes
Brakes
Forged Alloy Linear Pull
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Adjustable Height and Angle
Handlebar
Marin Alloy, 30mm Rise
Grips
Marin Commute
Headset
FSA, Threaded
Seat
Saddle
Marin Women's City + Sport Extra Plush
Seatpost
Alloy Suspension Post. 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.56 mm | 1.55 mm | 1.56 mm | 1.57 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm | 286 mm | 286 mm |
| Front Center | 624 mm | 639 mm | 654 mm | 663 mm | 678 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 76 mm | 76 mm | 76 mm | 73 mm | 73 mm |
| Stack | 582.55 mm | 610.83 mm | 624.97 mm | 641.28 mm | 660.19 mm |
| Reach | 386.72 mm | 391.99 mm | 402.12 mm | 411.5 mm | 419.99 mm |
| Top Tube Length | 588 mm | 603 mm | 618 mm | 633 mm | 648 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 503 mm | 559 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 140 mm | 170 mm | 185 mm | 200 mm | 220 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1073 mm | 1089 mm | 1104 mm | 1113 mm | 1128 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 526 mm | 527 mm | 529 mm | 777 mm | 824 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 161 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 164 cm | 174 cm | 182 cm | 189 cm | 193 cm |
Model Overview
Kentfield CS2 belongs to the Marin Kentfield model. Marin launched 33 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Marin Kentfield CS1 2020 is the most affordable bike of this model and has a price of 419$. On the other hand, Marin Kentfield CS2 2020, is the most expensive and costs 469$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Fitness bikes
Our math shows that the average cost of a dependable Fitness bike is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Marin Kentfield CS2 price was 469$. Comparing the average cost of a Fitness bike to this one, you will see that Kentfield CS2 price is 39.87% smaller.
Overview of components
Fork material
The fork on this bike is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When it comes to wheels, the Kentfield CS2 bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Kentfield CS2 has Rim brakes installed. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
Marin Kentfield CS2 bike has 5 sizes, in the range of 152 cm – 193 cm (4.99 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
