Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series One 6061 Aluminum, 700c Wheels, Step Through Top Tube
Suspension Fork
Full Alloy, Integrated 1 1/8”
Drivetrain
Rear Derailleur
Shimano Acera, 9 Speed
Front Derailleur
Shimano ALTUS 9-Speed
Shift Levers
Shimano ST-M65 Rapid Fire Plus, 9-Speed
Cassette
Shimano Alivio HG300, 12-36, 9-Speed
Crank
SR Suntour XCR With Replaceable Chainrings, 48/38/28T
Bottom Bracket
Sealed Cartridge
Chain
KMC X9, 9-Speed
Pedals
Composite Sport Flat Pedal
Wheels
Front Hub
Formula, 32 Hole
Rear Hub
Formula, 32 Hole with Cassette Freehub Body
Rims
Alex DC26, Double Wall with CNC Side Walls
Tires
Schwalbe Road Plus 700 x 38c with Kevlar Guard Puncture Protection and Reflective Sidewalls
Brakes
Brakes
Forged Alloy Linear Pull with Power Modulator
Brake Levers
Shimano with Integrated Shifters
Cockpit
Stem
Threadless Forged Alloy, Integrated Adjustment with -55° to +60° Rise
Handlebar
Double Butted 6061 Alloy, 25.4mm Clamp Diameter, 30mm Rise
Grips
Marin Ergonomic Locking
Headset
FSA, 1 1/8”
Seat
Saddle
Marin Women’s City Sport Extra Plush With Comfort Base
Seatpost
Suspension Post, 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Front Center | 624 mm | 639 mm | 654 mm | 663 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 588 mm | 603 mm | 618 mm | 633 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm | 520.7 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 71 ° |
| Head Tube Length | 140 mm | 170 mm | 185 mm | 200 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1073 mm | 1089 mm | 1104 mm | 1113 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
About this model
Kentfield CS3 belongs to the Marin Kentfield model. Marin launched 33 bikes of this model so far. Check out the entire range from 2015 of this model, by clicking this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
According to our math, the average price for a trustworthy Fitness bike is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels
The wheels on Kentfield CS3 are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Kentfield CS3 is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, they have problems in wet conditions.
Sizes
Marin Kentfield CS3 bike has 4 sizes, in the range of 151 cm – 184 cm (4.95 ft – 6.04 ft). In short, it won’t be difficult to find the right one for you.
