Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 City + Sport, 6061 Aluminum, 700C Wheels, Step Through Design, Fender and Rack Mounts
Suspension Fork
Aluminum, Straight Blade, Rack and Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Acera Shadow, 9-Speed
Front Derailleur
Shimano Altus
Shift Levers
Shimano EF510 3x9-Speed
Cassette
SunRace 9-Speed, 11-36T
Crank
SR Suntour XCR6, 48/36/26T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Spokes
14g Stainless Steel
Tires
Schwalbe Road Plus, 700Cx40, Reflective Sidewall, Kevlar Puncture Protection
Brakes
Brakes
Forged Alloy Linear Pull w/ Power Modulator
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Adjustable Height and Angle
Handlebar
Marin Alloy, 30mm Rise
Grips
Marin Ergonomic Locking
Headset
FSA, Threaded
Seat
Saddle
Marin Women's City + Sport Extra Plush
Seatpost
Alloy Suspension Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.56 mm | 1.55 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm |
| Front Center | 624 mm | 639 mm | 654 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 76 mm | 76 mm | 76 mm |
| Stack | 582.55 mm | 610.83 mm | 624.97 mm |
| Reach | 386.72 mm | 391.99 mm | 402.12 mm |
| Top Tube Length | 588 mm | 603 mm | 618 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 170 mm | 185 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1073 mm | 1089 mm | 1104 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 526 mm | 527 mm | 529 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Kentfield CS3 belongs to the Marin Kentfield model. Marin launched 33 bikes of this model so far. Take a sneak peek at all Marin Kentfield bikes models from 2018, by clicking here.
Model range prices
Marin Kentfield CS1 2018 is the cheapest bike model and costs 419$. Marin Kentfield CS2 2018 is the most expensive one and costs 469$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
As for the wheels, Marin Kentfield CS3 2018, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Kentfield CS3 has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
Sizes
Marin Kentfield CS3 bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
