Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Acera, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 City + Sport, 6061 Aluminum, 700C Wheels, Step Through Design, Fender and Rack Mounts
Suspension Fork
Aluminum, Straight Blade, Rack and Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Acera Shadow, 9-Speed
Front Derailleur
Shimano Altus
Shift Levers
Shimano EF510 3x9-Speed
Cassette
SunRace 9-Speed, 11-36T
Crank
SR Suntour XCR6, 48/36/26T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Spokes
14g Black Stainless Steel
Tires
Vee Tire, Zilent, 700x38, Wire Bead
Brakes
Brakes
Forged Alloy Linear Pull w/ Power Modulator
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Adjustable Height and Angle
Handlebar
Marin Alloy, 30mm Rise
Grips
Marin Ergonomic Locking
Headset
FSA, Threaded
Seat
Saddle
Marin Women's City + Sport Extra Plush
Seatpost
Alloy Suspension Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.56 mm | 1.55 mm |
| Bottom Bracket Height | 286 mm | 286 mm | 286 mm |
| Front Center | 624 mm | 639 mm | 654 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 76 mm | 76 mm | 76 mm |
| Stack | 582.55 mm | 610.83 mm | 624.97 mm |
| Reach | 386.72 mm | 391.99 mm | 402.12 mm |
| Top Tube Length | 588 mm | 603 mm | 618 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 140 mm | 170 mm | 185 mm |
| Chainstay Length | 458 mm | 458 mm | 458 mm |
| Wheelbase | 1073 mm | 1089 mm | 1104 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 526 mm | 527 mm | 529 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Kentfield CS3 is part of the Marin Kentfield model. Marin launched 33 bikes of this model so far. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Marin Kentfield CS1 2019 is the cheapest bike model and costs 399$. Marin Kentfield CS3 2019 is the most expensive one and costs 549$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Fitness bikes average price
If you want an acceptable Fitness bike you should know that the average price is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 549$. Comparing the average cost of a Fitness bike to this one, you will see that Kentfield CS3 price is 19.49% lower.
Overview of components
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The Kentfield CS3 2019 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Kentfield CS3 is equipped with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
