Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
152cm - 164cm
MD
161cm - 174cm
LG
171cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 City + Sport, 6061 Aluminum, 700C Wheels, Step Through Design, Fender and Rack Mounts
Suspension Fork
Steel, Moto Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney 7-Speed
Front Derailleur
-
Shift Levers
Shimano Altus 7-Speed RapidFire
Cassette
SunRace 7-Speed, 11-34T
Crank
Forged Alloy Crank, Steel 38T Chainring, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z-8.3
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire, GPVee, 700Cx40mm, Wire Bead, Flat Protection, Mixed Terrain Ready
Brakes
Brake Levers
Aluminum Lever
Cockpit
Stem
Marin Aluminum, 31.8mm Clamp
Handlebar
Marin Alloy, 30mm Rise, 12? Backsweep
Grips
Marin Adventure
Headset
FSA 888 Threadless
Seat
Saddle
Marin Adventure Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.66 mm | 1.61 mm | 1.6 mm |
| Bottom Bracket Height | 294.5 mm | 294.5 mm | 294.5 mm |
| Front Center | 642 mm | 667 mm | 689 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 74 mm |
| Stack | 638.6 mm | 653.4 mm | 671.5 mm |
| Reach | 385 mm | 405 mm | 420 mm |
| Top Tube Length | 572.7 mm | 596.9 mm | 617.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 422 mm | 462 mm | 495 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 190 mm | 205 mm | 225 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1087 mm | 1113 mm | 1135 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 515 mm | 528 mm | 548 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 161 cm | 171 cm |
| Rider Max Height | 164 cm | 174 cm | 180 cm |
About this model
Kentfield ST 1 completes the Marin Kentfield model. There are 33 bikes that carry this model name. You can easily view all of the Marin Kentfield bikes models from 2022, here.
Model range prices
Marin Kentfield 1 2022 is the cheapest bike model and costs 589$. Marin Kentfield 2 2022 is the most expensive one and costs 769$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fitness bikes
If you want an acceptable Fitness bike you should know that the average price is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2022 for 589$. Comparing the average cost of a Fitness bike to this one, you will see that Kentfield ST 1 price is 11.38% smaller.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The Kentfield ST 1 2022 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Kentfield ST 1 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
Marin Kentfield ST 1 bike has 3 sizes, in the range of 152 cm – 180 cm (4.99 ft – 5.91 ft). In short, it won’t be difficult to find the right one for you.
