Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
149cm - 164cm
MD
161cm - 169cm
LG
166cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 City + Sport, 6061 Aluminum, 700C Wheels, Step Through Design, Fender and Rack Mounts
Suspension Fork
Steel, Moto Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney 7-Speed
Front Derailleur
-
Shift Levers
Shimano Altus 7-Speed RapidFire
Cassette
SunRace 7-Speed, 11-34T
Crank
Forged Alloy Crank, Steel 38T Chainring, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire Co. GPVee, 700Cx40mm, Wire Bead, Flat Protection, Mixed Terrain Ready
Brakes
Brakes
Mechanical Disc
Brake Levers
Aluminum Lever
Cockpit
Stem
Marin Aluminum, 31.8mm Clamp
Handlebar
Marin Alloy, 30mm Rise, 12? Backsweep
Grips
Marin County
Headset
FSA 888 Threadless
Seat
Saddle
Marin Adventure Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.62 mm | 1.61 mm |
| Bottom Bracket Height | 294.5 mm | 294.5 mm | 294.5 mm |
| Front Center | 642 mm | 667 mm | 689 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 74 mm |
| Stack | 631.6 mm | 646.4 mm | 664.5 mm |
| Reach | 378 mm | 398 mm | 413 mm |
| Top Tube Length | 565.7 mm | 589.9 mm | 610.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 422 mm | 462 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 190 mm | 205 mm | 225 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1080 mm | 1106 mm | 1128 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 508 mm | 521 mm | 541 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 161 cm | 166 cm |
| Rider Max Height | 164 cm | 169 cm | 177 cm |
Model Overview
Kentfield ST 1 is part of the Marin Kentfield model. There are 33 bikes that carry this model name. Take a sneak peek at all Marin Kentfield bikes models from 2024, by clicking here.
Model range prices
Marin Kentfield ST 1 2024 is the most economical model, with a starting price of 499$. Marin Kentfield 2 2024 on the other hand costs 679$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fitness bikes average price
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2024 and its price was 499$. Comparing the average cost of a Fitness bike to this one, you will see that Kentfield ST 1 price is 31.46% smaller.
Kentfield ST 1 components
Fork material
Kentfield ST 1 has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The wheels on Kentfield ST 1 are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Kentfield ST 1 is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Marin Kentfield ST 1 bike has 3 sizes, in the range of 149 cm – 177 cm (4.89 ft – 5.81 ft). In short, you can easily find one that suits you.
