Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset microSHIFT Advent X -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
149cm - 164cm
MD
161cm - 169cm
LG
166cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 700C Wheels, Step Through Design, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
Steel, Moto Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
microSHIFT Advent X 10-Speed Wide Range
Front Derailleur
-
Shift Levers
microSHIFT Advent X 10-Speed
Cassette
microSHIFT 10-Speed, 11-48T
Crank
Forged Alloy Crank, Steel Narrow Wide 38T Chainring
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X10
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire Ci. GPVee, 700Cx40mm, Wire Bead, Flat Protection, Mixed Terrain Ready
Brakes
Brakes
Mechanical Disc
Brake Levers
Aluminum Lever
Cockpit
Stem
Marin Aluminum, 31.8mm Clamp
Handlebar
Marin Alloy, 30mm Rise, 12? Backsweep
Grips
Marin County
Headset
FSA 888 Threadless
Seat
Saddle
Marin Adventure Plush
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.67 mm | 1.62 mm | 1.61 mm |
| Bottom Bracket Height | 294.5 mm | 294.5 mm | 294.5 mm |
| Front Center | 642 mm | 667 mm | 689 mm |
| Rake | 50 mm | 50 mm | 50 mm |
| Trail | 74 mm | 74 mm | 74 mm |
| Stack | 631.6 mm | 646.4 mm | 664.5 mm |
| Reach | 378 mm | 398 mm | 413 mm |
| Top Tube Length | 565.7 mm | 589.9 mm | 610.4 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 422 mm | 462 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 190 mm | 205 mm | 225 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm |
| Wheelbase | 1080 mm | 1106 mm | 1128 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Standover Height | 508 mm | 521 mm | 541 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 161 cm | 166 cm |
| Rider Max Height | 164 cm | 169 cm | 177 cm |
Model Overview
Kentfield ST 2 belongs to the Marin Kentfield model. Marin released 33 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Marin Kentfield 1 2023 has a starting price of 499$. Marin Kentfield 2 2023 on the other hand is the most expensive at 679$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 679$. Comparing the average cost of a Fitness bike to this one, you will see that Kentfield ST 2 price is 3.51% higher.
Kentfield ST 2 components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The Kentfield ST 2 2023 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Kentfield ST 2 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike is available in 3 sizes. They vary from 149 cm – 177 cm (4.89 ft – 5.81 ft). In conclusion, finding one for you shouldn’t be a problem.
