Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Suspension Fork
Marin Full Carbon w/ Taper Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Tiagra 10-Speed
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra BR-RS405 10-Speed
Cassette
Shimano HG-500 Tiagra, 10-Speed, 11/34T
Crank
FSA Omega MexaExo, 50/34T
Bottom Bracket
FSA MegaExo BSA Threaded
Chain
KMC X10
Pedals
-
Wheels
Front Hub
Forged Aluminum Alloy, 100x12mm, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 21mm Inner, 30mm Tall, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire, G-Sport, 700x40C, Folding Bead, Tubeless Ready, Puncture Protection
Brakes
Brakes
Shimano Tiagra BR-RS405 Hydraulic
Brake Levers
Shimano BR-RS405 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Microfiber Tape
Headset
FSA Orbit, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.35 mm | 1.39 mm | 1.42 mm | 1.45 mm | 1.45 mm | 1.48 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 599 mm | 610 mm | 615 mm | 626 mm | 641 mm | 657 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Stack | 532.8 mm | 551.8 mm | 566 mm | 585 mm | 599.2 mm | 623 mm |
| Reach | 393.6 mm | 398.2 mm | 398.8 mm | 403.2 mm | 414 mm | 422 mm |
| Top Tube Length | 535 mm | 555 mm | 565 mm | 575 mm | 590 mm | 605 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 107 mm | 127 mm | 142 mm | 162 mm | 177 mm | 202 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1018 mm | 1029 mm | 1035 mm | 1045 mm | 1061 mm | 1077 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 752 mm | 779 mm | 797 mm | 816 mm | 834 mm | 855 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Lombard 2 is part of the Marin Lombard model. Marin released 13 bikes variations of this model so far. You can easily view all of the Marin Lombard bikes models from 2020, here.
Model range prices
The most economical model, the Marin Lombard 1 2020 has a starting price of 899$. Marin Lombard 2 2020 on the other hand is the most expensive at 1549$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Touring bikes average price
If you want an acceptable Touring bike you should know that the average price is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Marin Lombard 2 price was 1549$. Comparing the average cost of a Touring bike to this one, you will see that Lombard 2 price is 53.82% more expensive.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
Lombard 2 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
The Lombard 2 2020 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Lombard 2 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
