Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Marin Urban 6061 Aluminum, Double Butted with E4 Anti-Flex Seat & Chainstays with Forged Post Mount Disc Dropouts
Suspension Fork
Alloy Cross with Alloy Steerer tube
Drivetrain
Rear Derailleur
Shimano Sora
Front Derailleur
Shimano Sora
Shift Levers
Shimano Sora STI, 9-Speed
Cassette
Shimano HG200, 11-32, 9-Speed
Crank
Shimano Sora, 50/39/30T
Bottom Bracket
Shimano HollowTech II Integrated
Chain
KMC X9
Pedals
Full Alloy Sport Flat
Wheels
Front Hub
Formula, 32 Hole, 6-Bolt Disc
Rear Hub
Formula, 32 Hole
Rims
Maddux XCD22 29er, 32 Hole
Tires
Schwalbe Road Cruiser 700 x 35c with Kevlar Guard Puncture Protection
Brakes
Brakes
Promax Render R Mechanical Disc with 160mm Rotor
Brake Levers
Shimano with Integrated Shifters
Cockpit
Stem
Marin Alloy, Threadless, 31.8mm Clamp Diameter
Handlebar
Marin Butted Alloy OS 31.8mm Compact
Grips
Marin Road Plus Tape
Headset
FSA No. 8B 1 1/8 Threadless Sealed Cartridge Bearing
Seat
Saddle
Marin Fitness
Seatpost
Marin Comp Alloy Micro Adjust, 15mm Offset, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 276 mm | 276 mm | 278 mm | 278 mm | 278 mm | 278 mm |
| Front Center | 583 mm | 584 mm | 586 mm | 596 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 520 mm | 535 mm | 550 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 105 mm | 120 mm | 145 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1010 mm | 1011 mm | 1014 mm | 1024 mm | 1033 mm | 1043 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 765 mm | 782 mm | 805 mm | 823 mm | 842 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Lombard belongs to the Marin Lombard model. There are 13 bikes that carry this model name. Take a sneak peek at all Marin Lombard bikes models from 2015, by clicking here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
General Road bikes average price
If you want to purchase a solid General Road bike, it is important to know that the average cost is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Lombard components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on Lombard are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Lombard comes with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
