Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 700c -
Groupset X7, Apex -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Marin Urban 6061 Aluminum, Double Butted with E4 Anti-Flex Seat & Chainstays with Forged Post Mount Disc Dropouts
Suspension Fork
RFE Carbon with Alloy Steerer tube
Drivetrain
Rear Derailleur
SRAM X7 Type 2
Front Derailleur
SRAM Apex
Shift Levers
SRAM Apex Double-Tap10sp
Cassette
SRAM PG1020, 11-36, 10-Speed
Crank
FSA Gossamer, 50/34T
Bottom Bracket
FSA MegaExo
Chain
KMC X10SL DLC
Pedals
Full Alloy Sport Flat
Wheels
Front Hub
Formula, 32 Hole, 6-Bolt Disc
Rear Hub
Formula, 32 Hole
Rims
Alex ATD470 Disc, Tubeless Compatible
Tires
Clement X’Plor USH 700 x 35c Wire Bead
Brakes
Brakes
Avid BB7R Mechanical Disc, 6” Rotor
Brake Levers
SRAM with Integrated Shifters
Cockpit
Stem
Marin Alloy, Threadless, 31.8mm Clamp Diameter
Handlebar
Marin Butted Alloy OS 31.8mm Compact
Grips
Marin Road Plus Tape
Headset
FSA Orbit C, 1 1/8
Seat
Saddle
Marin Fitness
Seatpost
Marin Comp Alloy Micro Adjust, 15mm Offset, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 276 mm | 276 mm | 278 mm | 278 mm | 278 mm | 278 mm |
| Front Center | 583 mm | 584 mm | 586 mm | 596 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 520 mm | 535 mm | 550 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 105 mm | 120 mm | 145 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1010 mm | 1011 mm | 1014 mm | 1024 mm | 1033 mm | 1043 mm |
| Bottom Bracket Drop | 69 mm | 69 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 765 mm | 782 mm | 805 mm | 823 mm | 842 mm | 862 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Lombard Elite is a Marin Lombard model. Marin launched 13 bikes of this model so far. Take a sneak peek at all Marin Lombard bikes models from 2015, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
General Road bikes average price
According to our calculations, the average cost of a General Road bike that is reliable is 1915$. However, even if your budget is less than the average, you might still be able to get a top-quality General Road bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Fork material
Lombard Elite has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The Lombard Elite 2015 bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Lombard Elite has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
