Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Pike RC
-
Groupset XT -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Frame w/ Alloy Swingarm, 27.5” Wheels, 140mm Travel IsoTrac Suspension Platform, Chainstay Mounted Post Mount Disc Brake, 142x12mm Thru-Axle
Suspension Fork
RockShox Pike RC 27.5”, 140mm Travel, Compression and Rebound Adjustment, Solo Air Spring, 100x15mm Maxle Ultimate, 42mm Offset
Drivetrain
Rear Derailleur
Shimano RD-M8000 Deore XT SGS Shadow Plus
Front Derailleur
Marin Bear Claw Bottle Opener
Shift Levers
Shimano Deore XT 1x11-Speed, I-Spec II
Cassette
Shimano Deore XT 11-Speed, 11-46T
Crank
Shimano Deore XT Hollowtech II, 32T
Bottom Bracket
Shimano Hollowtech II
Chain
KMC X11L
Pedals
-
Wheels
Front Hub
Formula, 100x15mm, Sealed Cartridge Bearings, Centerlock Disc, 32H
Rear Hub
Formula, 142x12mm, Alloy Axle, Quad Cartridge Sealed Bearings, Centerlock Disc, 32H
Rims
Stan's NoTubes Flow MK3, 29mm Inner, Welded Joint, 32H, Tubeless Compatible
Tires
F: Schwalbe Nobby Nic Performance 27.5
Brakes
Brakes
Shimano Deore XT Hydraulic Disc, 180mm Centerlock Rotor
Brake Levers
Shimano Deore XT Hydraulic, I-Spec II
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm width, 4º up, 9º back
Grips
Marin Locking
Headset
FSA Orbit, Sealed Cartridge Bearings, 1 1/8
Seat
Saddle
WTB Volt Race
Seatpost
KS LEV Integra Dropper Post, Southpaw Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.4 mm | 1.38 mm | 1.39 mm |
| Bottom Bracket Height | 329.6 mm | 329.6 mm | 329.7 mm | 329.8 mm |
| Front Center | 691 mm | 707 mm | 724 mm | 741 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 98 mm | 98 mm | 96 mm | 99 mm |
| Stack | 594 mm | 603.1 mm | 612.2 mm | 630.6 mm |
| Reach | 419.5 mm | 431.9 mm | 444.2 mm | 454.1 mm |
| Top Tube Length | 588 mm | 602.9 mm | 617.9 mm | 633 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406.5 mm | 445.7 mm | 479.7 mm | 518.8 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.7 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 135 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1131 mm | 1147 mm | 1164 mm | 1181 mm |
| Bottom Bracket Drop | 23 mm | 23 mm | 23 mm | 23 mm |
| Standover Height | 714 mm | 732 mm | 756 mm | 774 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Mount Vision 8 completes the Marin Mount model. There are 23 bikes that carry this model name. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The RockShox Pike RC is included from the factory. It has a travel distance of 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, Marin Mount Vision 8 2017, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Mount Vision 8 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Mount Vision 8 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Marin model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
