Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Performance Elite Float 36
-
Groupset X01 Eagle, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Unidirectional Carbon Fiber Frame, Naild R3ACT – 2 Play Suspension Technology, 27.5" Wheels, 150mm Travel, 148mm Boost Rear Spacing, Bolt On Thru-Axle
Suspension Fork
Fox Performance Elite 36 27.5", 150mm Travel, GRIP 2 Damper, High and Low Speed Compression Adjustment, Rebound Adjustment, 110x15mm Boost Spacing, 44mm Offset
Rear Shock
Fox Float X2 Performance, 205x50mm, Low Speed Compression Adjustment, Low Speed Rebound Adjustment, Custom Tune, Trunnion Mount
Drivetrain
Rear Derailleur
SRAM X01 Eagle,12-Speed
Shift Levers
SRAM GX Eagle, 1x12-Speed
Cassette
SRAM XG-1295 12-Speed, 10-50T
Crank
SRAM Descendant Carbon, Direct Mount 12-Speed 32T, Boost Spacing, DUB, 170mm
Bottom Bracket
SRAM GXP BB92
Chain
SRAM GX Eagle
Pedals
Not Included.
Wheels
Front Hub
Forged Alloy, 110x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Alloy, 148x12mm, Quad Sealed Bearings, 6-Bolt Disc, 32H, XD Driver
Rims
Stan's NoTubes Sentry MK3, 32mm Inner, Welded Joint, BST Technology, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
WTB Trail Boss 27.5x2.6", Tri-Tech Triple Compound, Fast Rolling, Light Casing with Slash Guard, TCS Aramid Bead, Tubeless Compatible
Brakes
Brakes
Shimano XT 4 Piston, M8020, 203mm Rotor
Brake Levers
Shimano XT
Cockpit
Stem
Deity Copperhead Stem, 35mm
Handlebar
Deity Skyline, 787mm Width, 25mm Rise, Custom Color
Grips
Marin Locking
Headset
FSA Orbit, No. 42/47/ACB/S-4, Sealed Cartridge Bearings, 1 1/8"x 1 1/2”
Seat
Saddle
WTB Volt Race
Seatpost
KS LEV Integra Dropper Post, Southpaw Lever, Size S 125mm Travel, All Other Sizes: 150mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.33 mm | 1.31 mm | 1.28 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 742 mm | 769 mm | 795 mm | 822 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 116 mm | 116 mm | 117 mm | 117 mm |
| Stack | 581.6 mm | 595 mm | 613 mm | 625 mm |
| Reach | 427.2 mm | 448 mm | 466.5 mm | 488 mm |
| Top Tube Length | 576.2 mm | 598 mm | 621 mm | 645 mm |
| Seat Tube Angle | 75.5 ° | 75.3 ° | 75.1 ° | 75 ° |
| Seat Tube Length | 395 mm | 430 mm | 465 mm | 502 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 90 mm | 105 mm | 125 mm | 138 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 1155 mm | 1182 mm | 1208 mm | 1235 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 711 mm | 712 mm | 723 mm | 744 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 193 cm |
Model Overview
Mount Vision 9 is a Marin Mount model. There are 23 bikes that carry this model name. Take a sneak peek at all Marin Mount bikes models from 2020, by clicking here.
Model range prices
Marin Mount Vision 8 2020 is the cheapest bike model and costs 3749$. Marin Mount Vision Pro 2020 is the most expensive one and costs 6699$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Enduro bikes
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Marin Mount Vision 9 price was 4799$. In conclusion, this bike price is 33.34% more expensive than the price of the average Enduro bike.
Overview of components
Fork
The Mount Vision 9 comes factory-installed with the Fox Performance Elite Float 36 fork. This has a travel range of 150mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is Fox Float X2 Performance, with a travel distance of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Marin Mount Vision 9 2020, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Mount Vision 9 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 4 sizes. They vary from 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
