Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Pike RCT3
-
Groupset X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Frame and Swingarm, 27.5” Wheels, 140mm Travel IsoTrac Suspension Platform, Chainstay Mounted Post Mount Disc Brake, 142x12mm Thru-Axle
Suspension Fork
RockShox Pike RCT3 27.5”, 140mm Travel, Compression and Rebound Adjustment, Solo Air Spring, 100x15mm Maxle Ultimate, 42mm Offset
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Front Derailleur
Marin Bear Claw Bottle Opener
Shift Levers
SRAM X01 Eagle 1x12 Speed
Cassette
SRAM XG 1295 12-Speed, X01 Eagle, 10-50T
Crank
SRAM X01 Carbon, Direct Mount 34T Eagle Chainring
Bottom Bracket
SRAM GXP BSA
Chain
SRAM X01 Eagle 12-Speed
Pedals
-
Wheels
Front Hub
Stan's NoTubes Flow MRK3 Pro Wheelset, 100x15mm, 6-Bolt
Rear Hub
Stan's NoTubes Flow MRK3 Pro Wheelset, 12x142mm, 6-Bolt
Rims
Stan's NoTubes Flow MRK3 Pro Wheelset, 30mm inner
Tires
F: WTB Trail Boss 27.5”x2.4
Brakes
Brakes
SRAM Guide RS Hydraulic Disc, 180mm Rotors
Brake Levers
SRAM Guide RS
Cockpit
Stem
Gamut Cillos 3D Forged Alloy
Handlebar
Deity DC31 Mohawk Carbon
Grips
Marin Locking
Headset
FSA Orbit, Sealed Cartridge Bearings, 1 1/8
Seat
Saddle
WTB Volt Race
Seatpost
KS LEV Integra Dropper Post, Southpaw Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.4 mm | 1.38 mm | 1.39 mm |
| Bottom Bracket Height | 329.6 mm | 329.6 mm | 329.7 mm | 329.8 mm |
| Front Center | 691 mm | 707 mm | 724 mm | 741 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 98 mm | 98 mm | 96 mm | 99 mm |
| Stack | 594 mm | 603.1 mm | 612.2 mm | 630.6 mm |
| Reach | 419.5 mm | 431.9 mm | 444.2 mm | 454.1 mm |
| Top Tube Length | 588 mm | 602.9 mm | 617.9 mm | 633 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406.5 mm | 445.7 mm | 479.7 mm | 518.8 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.7 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 135 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1131 mm | 1147 mm | 1164 mm | 1181 mm |
| Bottom Bracket Drop | 23 mm | 23 mm | 23 mm | 23 mm |
| Standover Height | 714 mm | 732 mm | 756 mm | 774 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mount Vision Pro completes the Marin Mount model. There are 23 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork
This bike has the RockShox Pike RCT3 fork installed. The fork’s travel is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Mount Vision Pro bike is equipped with the 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Mount Vision Pro comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Marin model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
