Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Factory Float 36
-
Groupset XTR, e*thirteen TRS Race -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Full Unidirectional Carbon Fiber Frame, Naild R3ACT – 2 Play Suspension Technology, 27.5" Wheels, 150mm Travel, 148mm Boost Rear Spacing, Bolt On Thru-Axle
Suspension Fork
Fox Factory 36 27.5", 150mm Travel, GRIP 2 Damper, High and Low Speed Compression Adjustment, Rebound Adjustment, 110x15mm Boost Spacing, 44mm Offset
Rear Shock
Fox Float X2 Factory, 210x60mm, High and Low Speed Compression Adjustment, High and Low Speed Rebound Adjustment, Custom Tune, Trunnion Mount
Drivetrain
Rear Derailleur
New Shimano XTR, RD-M9100-SGS, Long Cage, Shadow Plus Design
Front Derailleur
-
Shift Levers
New Shimano XTR, SL-M9100-IR, I-Spec EV
Cassette
New Shimano XTR, CS-M9100
Crank
e*thirteen TRSr Carbon, 32T Ultralight Chainring, 170mm length
Bottom Bracket
Shimano XTR PF92
Chain
KMC 12 Speed with Quick Link
Pedals
-
Wheels
Front Hub
New Shimano XTR, Alloy Body, Cartridge Bearings, 110x15 E-Thru Axle, 28H
Rear Hub
New Shimano XTR, Alloy Body, Cartridge Bearings, 148x12 E-Thru Axle, 28H, Mircospline Freehub Body
Rims
e*thirteen TRS Race, Carbon Fiber Rim, 28H, 31mm Inner, Hookless, Tubeless Compatible
Spokes
The Hive Triple-Butted, Black, J-bend
Tires
Front: e*thirteen, TRS Race All-Terrain Tire, 27.5x2.35", 72tpi, Single Ply Apex Aramid Reinforced, Race Compound, Tubeless Compatible; Rear: e*thirteen, TRS PLUS All-Terrain Tire, 27.5x2.35", 72tpi, Race Compound, Tubeless Compatible
Brakes
Brakes
New Shimano XTR Enduro M9120 Hydraulic Disc Brakes, 203mm Rotor
Brake Levers
New Shimano XTR BLM9120
Cockpit
Stem
Deity Copperhead Stem, 35mm
Handlebar
Deity DC31 Mohawk Carbon Bar, 787mm Width, 25mm Rise, Custom Color
Grips
Marin Locking
Headset
FSA Orbit, No. 42/47/ACB/S-4, Sealed Cartridge Bearings, 1 1/8"x 1 1/2”
Seat
Saddle
WTB Volt Team, Ti Rails
Seatpost
Fox Transfer Performance Elite, Ano Black with 1x lever, Size S 120mm Travel, All Other Sizes: 150mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.33 mm | 1.31 mm | 1.28 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 742 mm | 769 mm | 795 mm | 822 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 116 mm | 116 mm | 117 mm | 117 mm |
| Stack | 581.6 mm | 595 mm | 613 mm | 625 mm |
| Reach | 427.2 mm | 448 mm | 466.5 mm | 488 mm |
| Top Tube Length | 576.2 mm | 598 mm | 621 mm | 645 mm |
| Seat Tube Angle | 75.5 ° | 75.3 ° | 75.1 ° | 75 ° |
| Seat Tube Length | 395 mm | 430 mm | 465 mm | 502 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 90 mm | 105 mm | 125 mm | 138 mm |
| Chainstay Length | 415 mm | 415 mm | 415 mm | 415 mm |
| Wheelbase | 1155 mm | 1182 mm | 1208 mm | 1235 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 711 mm | 712 mm | 723 mm | 744 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 193 cm |
Model Overview
Mount Vision Pro is a Marin Mount model. There are 23 bikes that carry this model name. Take a sneak peek at all Marin Mount bikes models from 2019, by clicking here.
Model range prices
The most economical model, the Marin Mount Vision 8 2019 has a starting price of 4999$. Marin Mount Vision Pro 2019 on the other hand is the most expensive at 8499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Enduro bikes
According to our calculations, the average cost of an Enduro bike that is reliable is 3599$. However, you could also get a good Enduro bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Marin released this model in 2019, its price was 8499$. Comparing this to the average Enduro bike price, we see that the price is 136.15% higher.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 36 model. The travel on this model is 150mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is Fox Float X2 Factory, with a travel distance of 150mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Mount Vision Pro 2019 bike is equipped with 27.5″ carbon wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Mount Vision Pro comes in 4 sizes, that range from 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Marin Mount Vision Pro comes with a dropper post. Therefore, climbing or descending will be a breeze.
