Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork SunTour EPIXON
-
Groupset Alivio, SLX -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mount Vision Alloy Frame with SHOT Tech, 140mm Travel IsoTrac Suspension System, 27.5”Wheels, Tapered Headtube, 142 x 12mm Thru-Axle
Suspension Fork
SR Suntour Epixon with 15mm Thru-Axle, 140mm Travel
Drivetrain
Rear Derailleur
Shimano Alivio, 9-Speed
Front Derailleur
Shimano SLX, High Direct Mount, 9-Speed
Shift Levers
Shimano Alivio, 9-Speed
Cassette
Shimano Alivio HG300, 12-36, 9-Speed
Crank
Shimano Alivio, 44/32/22T
Bottom Bracket
Shimano Octalink Splined
Chain
KMC X9, 9-Speed
Pedals
None
Wheels
Front Hub
Marin 100 x 15mm Through Axle, 32 Hole
Rear Hub
Marin 4 Sealed Bearing, 142 x 12mm Through Axle
Rims
Alex DP21, 27.5”, 32-Hole
Tires
Schwalbe Nobby Nic, Performance, 27.5 x 2.25
Brakes
Brakes
Tektro Auriga Hydraulic Disc, 7” Rotor
Brake Levers
Tektro Hydraulic
Cockpit
Stem
Marin Alloy, Threadless
Handlebar
Double Butted 6061 Alloy, OS-31.8mm, 10mm Rise, 740mm Wide
Grips
Marin Dual Density
Headset
FSA Orbit 1.5B-1 ZS
Seat
Saddle
Marin Comp Mountain
Seatpost
Marin Alloy Micro Adjust, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.4 mm | 1.38 mm | 1.39 mm |
| Bottom Bracket Height | 329.6 mm | 329.6 mm | 329.7 mm | 329.8 mm |
| Front Center | 691 mm | 707 mm | 724 mm | 741 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 98 mm | 98 mm | 96 mm | 99 mm |
| Stack | 594 mm | 603.1 mm | 612.2 mm | 630.6 mm |
| Reach | 419.5 mm | 431.9 mm | 444.2 mm | 454.1 mm |
| Top Tube Length | 588 mm | 602.9 mm | 617.9 mm | 633 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406.5 mm | 445.7 mm | 479.7 mm | 518.8 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.7 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 135 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1131 mm | 1147 mm | 1164 mm | 1181 mm |
| Bottom Bracket Drop | 23 mm | 23 mm | 23 mm | 23 mm |
| Standover Height | 714 mm | 732 mm | 756 mm | 774 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Mount Vision XM5 belongs to the Marin Mount model. Marin launched 23 bikes of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
This bike has the SunTour EPIXON fork installed. The fork’s travel is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Mount Vision XM5 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Mount Vision XM5 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Mount Vision XM5 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
