Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Sektor
-
Groupset XT, Deore -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mount Vision Series Four Alloy Frame with 140mm Travel IsoTrac Suspension System, 27.5”Wheels, Tapered Headtube, 142 x 12mm Thru
Suspension Fork
Rock Shox Sektor Silver TK Taper Solo Air, 15mm Maxle Light, 140mm Travel
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus, Medium Cage, Direct Mount
Front Derailleur
Shimano DEORE, 2x10-Speed Direct Mount
Shift Levers
Shimano DEORE, 2 Way Release, 10-Speed
Cassette
Shimano DEORE, 11-36, 10-Speed
Crank
Shimano Deore 2x10, 38/24T
Bottom Bracket
Shimano HollowTech II Integrated
Chain
Shimano HG54
Pedals
None
Wheels
Front Hub
Marin 2 Sealed Bearings, Centerlock, 15mm Through Axle, 32-Hole
Rear Hub
Marin 4 Sealed Bearing, Centerlock, 142 x 12mm Through Axle
Rims
Alex DP21 with SSE, 27.5”, 32-Hole
Tires
Schwalbe Nobby Nic, Performance, 27.5 x 2.25
Brakes
Brakes
Shimano M445 Hydraulic Disc, Centerlock, 7” Rotor
Brake Levers
Shimano Hydraulic
Cockpit
Stem
Marin OS Alloy Threadless, 31.8mm Bar Clamp
Handlebar
Double Butted 6061 Alloy, OS-31.8mm, 10mm Rise, 740mm Wide
Grips
Marin Micro-Knurl Double Locking
Headset
FSA Orbit 1.5B ZS, 1 1/8” Top, 1.5” Bottom
Seat
Saddle
WTB VOLT Comp
Seatpost
Marin Comp Alloy Micro Adjust, 2014 Alloy, 15mm Offset, 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.4 mm | 1.38 mm | 1.39 mm |
| Bottom Bracket Height | 329.6 mm | 329.6 mm | 329.7 mm | 329.8 mm |
| Front Center | 691 mm | 707 mm | 724 mm | 741 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 98 mm | 98 mm | 96 mm | 99 mm |
| Stack | 594 mm | 603.1 mm | 612.2 mm | 630.6 mm |
| Reach | 419.5 mm | 431.9 mm | 444.2 mm | 454.1 mm |
| Top Tube Length | 588 mm | 602.9 mm | 617.9 mm | 633 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 406.5 mm | 445.7 mm | 479.7 mm | 518.8 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.7 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 135 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1131 mm | 1147 mm | 1164 mm | 1181 mm |
| Bottom Bracket Drop | 23 mm | 23 mm | 23 mm | 23 mm |
| Standover Height | 714 mm | 732 mm | 756 mm | 774 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Mount Vision XM6 is a Marin Mount model. 23 bikes variations carry this model name so far. Take a sneak peek at all Marin Mount bikes models from 2015, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The Mount Vision XM6 comes factory-installed with the RockShox Sektor fork. This has a travel range of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
As for the wheels, Marin Mount Vision XM6 2015, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Mount Vision XM6 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
