Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Alivio, Altus -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 189cm
XXL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Butted CrMo, 29” Wheels, Integrated Headset, Disc Brake, Fender and Rack Mounts
Suspension Fork
CrMo, Fender and Rack Eyelets, Disc Brake
Drivetrain
Rear Derailleur
Shimano Alivio Shadow 9-Speed
Front Derailleur
Shimano Altus
Shift Levers
Shimano Altus 3x9-Speed
Cassette
Shimano HG300 9-Speed, 12-36T
Crank
Forged Alloy, 48/36/26T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum, Double Wall, Disc Specific
Tires
Vee Tire, Speedster, 700Cx40mm, Puncture Protection, Reflective Sidewall, Wire Bead
Brakes
Brake Levers
Shimano Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Alloy Flat Top Riser
Grips
Marin Custom
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
Marin Fitness
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.37 mm | 1.35 mm | 1.37 mm | 1.42 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 617 mm | 634 mm | 650 | 654 mm | 658 mm |
| Rake | 51 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 66 mm | 67 mm | 65 mm | 67 mm | 66 mm |
| Stack | 565 mm | 572 mm | 581 mm | 591 mm | 610 mm |
| Reach | 385 mm | 418 mm | 430 mm | 432 mm | 429 mm |
| Top Tube Length | 548 mm | 588 mm | 603 mm | 613 mm | 628 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72 ° |
| Seat Tube Length | 381 mm | 432 mm | 483 mm | 521 mm | 559 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 123 mm | 123 mm | 133 mm | 143 mm | 163 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1050 mm | 1068 mm | 1084 mm | 1088 mm | 1092 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 661 mm | 703 mm | 746 mm | 777 mm | 809 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 160 cm | 166 cm | 174 cm | 181 cm | 187 cm |
| Rider Max Height | 169 cm | 177 cm | 184 cm | 189 cm | 193 cm |
Model Overview
Muirwoods is a Marin Muirwoods model. Marin launched 13 bikes of this model so far. Take a sneak peek at all Marin Muirwoods bikes models from 2021, by clicking here.
Model range prices
Marin Muirwoods 2021 is the most affordable bike of this model and has a price of 829$. On the other hand, Marin Muirwoods RC 2021, is the most expensive and costs 1159$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter bikes
If you want an acceptable Commuter bike you should know that the average price is 762$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 829$. Comparing the average cost of a Commuter bike to this one, you will see that Muirwoods price is 8.79% higher.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
As for the wheels, Marin Muirwoods 2021, has a 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Muirwoods is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Muirwoods comes in 5 sizes, that range from 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
