Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, Double Butted Frame, Internal Shifter & Dropper Post Routing, 142x12mm Thru-Axle
Suspension Fork
RockShox Recon Silver RL, 120mm of travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, Solo Air Spring, 100x15mm Thru-Axle, 51mm Offset
Drivetrain
Rear Derailleur
SRAM NX 11-Speed
Front Derailleur
-
Shift Levers
SRAM NX 1x11-Speed
Cassette
Sunrace 11-Speed, 11-42T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD
Bottom Bracket
External Sealed Cartridge Bearings
Chain
SRAM 110 11-Speed
Pedals
Resin Platform
Wheels
Front Hub
Formula, 100x15mm, Sealed Cartridge Bearings, Centerlock Disc, 32H
Rear Hub
Formula, 142x12mm, Quad Sealed Cartridge Bearings, Alloy Axle, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 27mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Tires
F: Schwalbe Nobby Nic Performance 2.25
Brakes
Brakes
Shimano BR-M445 Hydraulic Disc, 180mm Centerlock Rotor
Brake Levers
Shimano BL-445 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm width, 4º up, 9º back
Grips
Marin Locking
Headset
FSA Orbit, Sealed Cartridge Bearings, 1 1/8
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy Light
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.41 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 311.5 mm | 311.5 mm | 311.5 mm |
| Front Center | 691 mm | 709 mm | 734 mm | 752 mm | 763 mm |
| Rake | 44 mm | 44 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 89 mm | 89 mm | 89 mm |
| Stack | 595.5 mm | 600.2 mm | 628.33 mm | 632.96 mm | 637.6 mm |
| Reach | 416 mm | 432 mm | 444.26 mm | 459.93 mm | 469.6 mm |
| Top Tube Length | 588 mm | 605 mm | 625 mm | 642 mm | 653 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1110 mm | 1128 mm | 1161 mm | 1178 mm | 1190 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 59 mm | 59 mm | 59 mm |
| Standover Height | 694 mm | 732 mm | 780 mm | 810 mm | 842 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
About this model
Nail Trail 6 completes the Marin Nail model. Marin released 15 bikes variations of this model so far. You can easily view all of the Marin Nail bikes models from 2017, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Marin Nail Trail 6 2017, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Nail Trail 6 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
