Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, 27.5” Wheels, Double Butted Frame, Internal Shifter and Dropper Post Routing, 148x12mm Boost Thru-Axle
Suspension Fork
RockShox Recon RL 27.5", 120mm Travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Stealth, 51mm Offset
Drivetrain
Rear Derailleur
SRAM NX 11-Speed
Front Derailleur
- - -
Shift Levers
SRAM NX 1x11-Speed
Cassette
SunRace 11-Speed, 11-42T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11 Extra Light
Pedals
Nylon Platform
Wheels
Front Hub
Formula, 110x15mm, Sealed Cartridge Bearings, Centerlock Disc, 32H
Rear Hub
Formula, 148x12mm, Quad Sealed Cartridge Bearings, Alloy Axle, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire, Crown Gem 29x2.3"/27.5x2.3", Dual Control Compound, Wire Bead
Brakes
Brakes
Shimano BR-M425 Hydraulic Disc, 180mm Centerlock Rotor
Brake Levers
Shimano BL-425 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 45mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy Light
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.39 mm | 1.41 mm | 1.38 mm | 1.36 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 311.5 mm | 311.5 mm | 311.5 mm |
| Front Center | 691 mm | 709 mm | 734 mm | 752 mm | 763 mm |
| Rake | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 89 mm | 89 mm | 89 mm |
| Stack | 595.5 mm | 600.2 mm | 628.33 mm | 632.96 mm | 637.6 mm |
| Reach | 416 mm | 432 mm | 444.26 mm | 459.93 mm | 469.6 mm |
| Top Tube Length | 588 mm | 605 mm | 625 mm | 642 mm | 653 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm | 559 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 423 mm | 423 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1110 mm | 1128 mm | 1161 mm | 1178 mm | 1190 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 59 mm | 59 mm | 59 mm |
| Standover Height | 694 mm | 732 mm | 780 mm | 810 mm | 842 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
Model Overview
Nail Trail 6 completes the Marin Nail model. 15 bikes variations carry this model name so far. Take a sneak peek at all Marin Nail bikes models from 2019, by clicking here.
Model range prices
Marin Nail Trail 6 2019 is the most affordable bike of this model and has a price of 1299$. On the other hand, Marin Nail Trail 7 2019, is the most expensive and costs 1799$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1299$. Comparing this to the average Trail bike price, we see that the price is 112.63% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Nail Trail 6 components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Marin Nail Trail 6 2019, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Nail Trail 6 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
