Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Fox Performance Float 32
-
Groupset GX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum w/ SHOT Tech, 29” Wheels
Suspension Fork
Fox 32 Float Performance 29”, 100mm Travel
Drivetrain
Rear Derailleur
SRAM GX1
Shift Levers
SRAM GX 1x11-Speed
Cassette
Sunrace 11-Speed, 11-42T
Crank
Forged Alloy 1x11, Hollow CrMo Spindle, Narrow-Wide 32T
Bottom Bracket
External Sealed Cartridge Bearing
Chain
KMC X11L
Wheels
Front Hub
Formula, 100x15mm, Sealed Cartridge Bearing, Centerlock Disc, 32H
Rear Hub
Formula, Quad Sealed Cartridge Bearings, Alloy Axle, Centerlock Disc, 32H
Rims
Maddux HD520, Double Wall, Disc Specific, 22.5mm Inner, Tubeless Ready
Tires
Schwalbe Racing Ralph Performance, 29x2.25”, Folding
Brakes
Brakes
Shimano Deore Hydraulic Disc, 180mm Centerlock Rotor
Brake Levers
Shimano Deore Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Flat Top Riser
Grips
Marin Locking
Headset
FSA Orbit, Sealed Cartridge Bearing, 1 1/8
Seat
Saddle
Marin MTB
Seatpost
Trans-X Dropper Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.48 mm | 1.49 mm | 1.42 mm | 1.4 mm | 1.42 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 659 mm | 678 mm | 698 mm | 715 mm | 730 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 82 mm | 82 mm | 82 mm | 82 mm | 82 mm |
| Stack | 599 mm | 618.3 mm | 618.3 mm | 627.7 mm | 646.5 mm |
| Reach | 403.5 mm | 414.9 mm | 434.9 mm | 449.2 mm | 456.7 mm |
| Top Tube Length | 578 mm | 595 mm | 615 mm | 632 mm | 645 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm | 559 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 110 mm | 110 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1095 mm | 1114 mm | 1134 mm | 1151 mm | 1166 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 693 mm | 741 mm | 781 mm | 813 mm | 847 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
Model Overview
Nail Trail 9.7 belongs to the Marin Nail model. There are 15 bikes that carry this model name. Check out the entire range from 2016 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Nail Trail 9.7 components
Fork
The Nail Trail 9.7 comes factory-installed with the Fox Performance Float 32 fork. This has a travel range of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Nail Trail 9.7 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Nail Trail 9.7 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
Marin Nail Trail 9.7 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
