Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b -
Groupset Rival 1, FSA -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 CrMo, Beyond Road Geometry, Thru- Axle, Disc Brake, Integrated Headset, Fender and Rack Mounts
Suspension Fork
Marin Full Carbon w/ Taper Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
SRAM Rival 1
Front Derailleur
---
Shift Levers
SRAM Rival 1x11 Speed, Left Side ModifiedFor Dropper Post Lever
Cassette
e*thirteen TRS 11-Speed, 9-44T
Crank
FSA Gossamer Pro, 1x11 Megatooth, 42T Chainring, BB392EVO Alloy Spindle
Bottom Bracket
FSA BB-EVO7000, BSA Threaded
Chain
KMC X11
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 100x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 142x12mm, Alloy Axle, Quad Cartridge Sealed Bearings, SRAM XD Driver, 6-Bolt Disc, 32H
Rims
WTB KOM i25, 25mm Inner, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
WTB Byway, 650Bx47, Folding Bead, Tubeless Compatible
Brakes
Brakes
SRAM Rival Hydraulic
Brake Levers
SRAM Rival Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12° Flared Drop
Grips
Marin Shock Absorbing Perforated Tape
Headset
FSA Orbit IS, Sealed Cartridge Bearings, 1 1/8” x 1 3/8”
Seat
Saddle
Marin Beyond Road Concept
Seatpost
TranzX YSP11 Dropper Post, 105mm Travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.55 mm | 1.53 mm | 1.54 mm | 1.53 mm | 1.53 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 583 mm | 591 mm | 585 mm | 590 mm | 599 mm | 620 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 52 mm | 68 mm | 82 mm | 83 mm | 94 mm | 83 mm |
| Stack | 502 mm | 566 mm | 577 mm | 593.5 mm | 612.4 mm | 622 mm |
| Reach | 364.5 mm | 365 mm | 377 mm | 386.2 mm | 400.4 mm | 406.5 mm |
| Top Tube Length | 517 mm | 527 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm | 200 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 994 mm | 1002 mm | 995 mm | 1001 mm | 1010 mm | 1031 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 723 mm | 743 mm | 760 mm | 779 mm | 798 mm | 814 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
Model Overview
Nicasio Ridge is a Marin Nicasio model. There are 25 bikes that carry this model name. Take a sneak peek at all Marin Nicasio bikes models from 2019, by clicking here.
Model range prices
Marin Nicasio 2019 is the cheapest bike model and costs 759$. Marin Nicasio Ridge 2019 is the most expensive one and costs 2599$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2019 and its price was 2599$. Doing a quick comparison, we notice that Nicasio Ridge price is 5.56% more expensive than the average cost of a Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Nicasio Ridge are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Nicasio Ridge has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Dropper post
The Marin model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
