Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted CrMo Single Speed w/Sliding Dropouts, 700C Wheels, Disc Brake, Beyond Road Geometry, Fender and Rack Mounts
Suspension Fork
CrMo, Fender and Rack Eyelets, IS Disc
Drivetrain
Rear Derailleur
-
Front Derailleur
-
Shift Levers
-
Cassette
Single Speed Cassette Cog, 17T
Crank
Forged Aluminum Alloy Arm, 42T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z410RB w/ Anti-Corrosion Coating
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 19mm Inner, Disc Specific
Tires
Schwalbe Spicer, 700Cx30
Brakes
Brakes
Promax Render R Road Mechanical Disc, 160mm Rotor
Brake Levers
Alloy Drop Bar, Disc
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Compact 12º Flared Drop
Grips
Marin Comfort Tape
Headset
FSA No.8D, Sealed Cartridge Bearings
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.5 mm | 1.53 mm | 1.51 mm | 1.53 mm | 1.52 mm | 1.52 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 583 mm | 591 mm | 585 mm | 590 mm | 599 mm | 620 mm | 629 mm |
| Rake | 57 mm | 57 mm | 57 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 62 mm | 59 mm | 70 mm | 65 mm | 59 mm | 59 mm | 59 mm |
| Stack | 540.57 mm | 547.26 mm | 561.4 mm | 580.52 mm | 596.64 mm | 615.72 mm | 625.25 mm |
| Reach | 355.75 mm | 365.8 mm | 366.48 mm | 384.42 mm | 390.42 mm | 404.59 mm | 410.75 mm |
| Top Tube Length | 504 mm | 521 mm | 531 mm | 551 mm | 571 mm | 591 mm | 606 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm | 200 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 998 mm | 1006 mm | 999 mm | 1005 mm | 1014 mm | 1035 mm | 1044 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 703 mm | 727 mm | 747 mm | 764 mm | 783 mm | 802 mm | 818 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Nicasio SS belongs to the Marin Nicasio model. Marin launched 25 bikes of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Gravel bikes
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Nicasio SS components
Fork material
Nicasio SS has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
When leaving the production line, the Nicasio SS model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Nicasio SS has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
