Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset microSHIFT Advent, FSA -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Double Butted CrMo Beyond Road, 650B Wheels, Beyond Road Geometry, Fender and Rack Mounts, Disc Mount
Suspension Fork
CrMo, Fender and Rack Eyelets, IS Disc Mount
Drivetrain
Rear Derailleur
microSHIFT Advent, 1x9 w/ Clutch Mech
Front Derailleur
N/A
Shift Levers
microSHIFT Advent, 1x9 Specific
Cassette
SunRace 9-Speed, 11-46T
Crank
FSA Vero Pro, Narrow Wide, 42T
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Marin Oso OEM Nylon Platform
Wheels
Front Hub
Forged Aluminum Alloy, Disc, 32H
Rear Hub
Forged Aluminum Alloy, Disc, 32H
Rims
Marin Aluminum Double Wall, 25mm Inner, Disc Specific
Tires
WTB Horizon, 650Bx47mm
Brakes
Brakes
Mechanical Disc
Brake Levers
microSHIFT Advent
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Comfort Tape
Headset
FSA ORBIT CE No.8B, Sealed Cartridge Bearings
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.5 mm | 1.53 mm | 1.51 mm | 1.53 mm | 1.52 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm | 269 mm |
| Front Center | 583 mm | 591 mm | 585 mm | 590 mm | 599 mm | 620 mm |
| Rake | 57 mm | 57 mm | 57 mm | 45 mm | 45 mm | 45 mm |
| Trail | 59 mm | 56 mm | 68 mm | 63 mm | 57 mm | 57 mm |
| Stack | 540.57 mm | 547.26 mm | 561.4 mm | 580.52 mm | 596.64 mm | 615.72 mm |
| Reach | 355.75 mm | 365.8 mm | 366.48 mm | 384.42 mm | 390.42 mm | 404.59 mm |
| Top Tube Length | 504 mm | 521 mm | 531 mm | 551 mm | 571 mm | 591 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 125 mm | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 998 mm | 1006 mm | 999 mm | 1005 mm | 1014 mm | 1035 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 703 mm | 727 mm | 747 mm | 764 mm | 783 mm | 802 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
Model Overview
Nicasio+ is part of the Marin Nicasio model. Marin launched 25 bikes of this model so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Marin Nicasio 2024 is the cheapest bike model and costs 899$. Marin Nicasio 2 2024 is the most expensive one and costs 1699$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2024 for 1099$. If we compare this with the average Gravel bike cost we notice that the price is 124.02% smaller.
Nicasio+ components
Fork material
The fork on this bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The Nicasio+ 2024 bike is equipped with aluminum wheels when leaving the factory. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Nicasio+ has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
