Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
169cm - 179cm
LG
176cm - 184cm
XL
181cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Double Butted CrMo, 29" Wheels, Boost 141x9mm Open Dropout, 73mm Threaded BB, Plentiful Gear Mounts
Suspension Fork
RockShox Recon RL, 120mm Travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Stealth, 42mm Offset
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus SGS
Front Derailleur
-
Shift Levers
MicroSHIFT 1x11-Speed
Cassette
SunRace 11-Speed, 11-46T
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow-Wide 32T Chainring, 76mm BCD
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 110x15mm, 6-Bolt Disc, 32H
Rear Hub
Forged Alloy, 141x9mm, 6-Bolt Disc, 32H
Rims
Alloy Double-Wall, Offset Spoke, 32mm ID, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire Flow Snap, 29x2.6", Wire Bead
Brakes
Brakes
Shimano MT420, 4-Piston, Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano MT400 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Pine Mountain Trail Bar, 50mm Rise, 780 Width, 10? Backsweep, 6? Upsweep
Grips
Marin BearPaw Locking
Headset
FSA Orbit ITA, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Pine Mountain Trail
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.47 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 714 mm | 736 mm | 763 mm | 797 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 107 mm | 107 mm | 107 mm | 107 mm |
| Stack | 624 mm | 628.6 mm | 633.2 mm | 642 mm |
| Reach | 408 mm | 428 mm | 453 mm | 483 mm |
| Top Tube Length | 570 mm | 591 mm | 617.3 mm | 649.6 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1135 mm | 1157 mm | 1184 mm | 1218 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 692 mm | 738 mm | 782 mm | 815 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 169 cm | 176 cm | 181 cm |
| Rider Max Height | 172 cm | 179 cm | 184 cm | 188 cm |
Model Overview
Pine Mountain 1 completes the Marin Pine model. Marin released 21 bikes variations of this model so far. You can easily view all of the Marin Pine bikes models from 2020, here.
Model range prices
Marin Pine Mountain 1 2020 is the most economical model, with a starting price of 1299$. Marin Pine Mountain 2 2020 on the other hand costs 2099$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Marin released this model in 2020, its price was 1299$. Doing a quick comparison, we notice that Pine Mountain 1 price is 112.63% lower than the average cost of a Trail bike.
Pine Mountain 1 components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
The wheels on Pine Mountain 1 are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Marin Pine Mountain 1 bike has 4 sizes, in the range of 162 cm – 188 cm (5.31 ft – 6.17 ft). In conclusion, you won’t have a problem finding one that suits you.
