Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset SLX, FSA -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Double Butted and Heat Treated CrMo, 29" Wheels, Custom Cast Boost 148x12mm Dropouts, 148x12mm Thru-Axle, 73mm Threaded BB, Plentiful Gear Mounts
Suspension Fork
RockShox FS 35, 120mm Travel, DebonAir, Alloy Tapered Steerer, 110x15mm Boost Spacing, Maxle Lite, 44mm Offset
Drivetrain
Rear Derailleur
Shimano SLX 12-Speed
Front Derailleur
-
Shift Levers
Shimano SLX 12-Speed
Cassette
Shimano SLX M7100 Cassette, 12-Speed, 10-51T
Crank
FSA Grid, Modular 1x, 32T Direct Mount MegaTooth Chainring
Bottom Bracket
FSA Outboard Cartridge Bearings
Chain
KMC X12
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 110x15mm, Sealed Cartridge Bearings, Centerlock Disc, 32H
Rear Hub
Shimano, Microspline 148x12mm, Centerlock Disc, 32H
Rims
Alloy Double-Wall, Offset Spoke, 32mm ID, Tubeless Compatible
Tires
Vee Tire Flow Snap, 29x2.6", Folding Bead, Tubeless Ready
Brakes
Brake Levers
Shimano MT500 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Bedroll Bar, 50mm Rise, 780 Width, 10? Backsweep, 6? Upsweep
Grips
Marin BearPaw Locking
Headset
FSA Orbit ITA, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Pine Mountain Trail
Seatpost
TranzX Dropper Post, YSP23 w/ 1x Remote, Size S 150mm Travel, All Other Sizes: 170mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.47 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 315 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 714 mm | 736 mm | 763 mm | 797 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 107 mm | 107 mm | 107 mm | 107 mm |
| Stack | 624 mm | 628.6 mm | 633.2 mm | 642 mm |
| Reach | 408 mm | 428 mm | 453 mm | 483 mm |
| Top Tube Length | 570 mm | 591 mm | 617.3 mm | 649.6 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 95 mm | 100 mm | 105 mm | 115 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1135 mm | 1157 mm | 1184 mm | 1218 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 692 mm | 738 mm | 782 mm | 815 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 169 cm | 177 cm | 184 cm | 190 cm |
About this model
Pine Mountain 2 belongs to the Marin Pine model. 21 bikes variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Marin Pine Mountain 1 2022 is the most economical model, with a starting price of 1579$. Marin Pine Mountain 2 2022 on the other hand costs 2499$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Marin released this model in 2022, its price was 2499$. In conclusion, this bike price is 10.52% lower than the price of the average Trail bike.
Pine Mountain 2 components
Fork
The Pine Mountain 2 comes factory-installed with the RockShox 35 Gold RL fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
Pine Mountain 2 has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels size
The Pine Mountain 2 2022 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Pine Mountain 2 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Marin Pine Mountain 2 bike has 4 sizes, in the range of 160 cm – 190 cm (5.25 ft – 6.23 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Marin model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
