Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 27.5" -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Double Butted CrMo, 27.5+ Wheels, Boost 141x9mm Open Dropouts
Suspension Fork
CrMo, Thru-Axle, Suspension Corrected, Boost 110mm Spacing, QR Lever
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus SGS 10-Speed
Front Derailleur
- - -
Shift Levers
Shimano Deore 1x10-Speed
Cassette
SunRace 10-Speed, 11-42T
Crank
Marin Forged Alloy 1x10, Hollow Spindle, Direct Mount Steel Forged Narrow-Wide 32T Chainring, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X10
Pedals
Nylon Platform
Wheels
Front Hub
Joytech, 110x9mm, 6-Bolt Disc, 32H
Rear Hub
Joytech, 141x9mm, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 38mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire, Crown Gem 27.5x2.8", Dual Control Compound, Folding Bead, Tubeless Compatible
Brakes
Brakes
Shimano BR-M425 Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano BL-425 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 60mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 780mm Width, 4º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA Orbit ITA, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin MTB
Seatpost
Marin Alloy Light
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.44 mm | 1.38 mm | 1.39 mm | 1.42 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 311 mm | 311 mm | 311 mm |
| Front Center | 654 mm | 687 mm | 710 mm | 723 mm | 745 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 87 mm | 82 mm | 83 mm | 82 mm | 82 mm |
| Stack | 602 mm | 602 mm | 607 mm | 621 mm | 649 mm |
| Reach | 389 mm | 417 mm | 439 mm | 446 mm | 457 mm |
| Top Tube Length | 568 mm | 596 mm | 619 mm | 642 mm | 662 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm | 559 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 105 mm | 120 mm | 150 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1083 mm | 1116 mm | 1139 mm | 1152 mm | 1174 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 702 mm | 742 mm | 775 mm | 813 mm | 854 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
About this model
Pine Mountain belongs to the Marin Pine model. Marin launched 21 bikes of this model so far. You can easily view all of the Marin Pine bikes models from 2018, here.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
When leaving the production line, the Pine Mountain model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
