Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 29” Wheels, 120mm Travel MultiTrac Suspension Platform, Seatstay Mounted Post Mount Disc Brakes, 141x9mm Boost Closed 9 to 12 Thru Axle System (upgradable to 148x12mm)
Suspension Fork
RockShox Recon RL 29”, 120mm Travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, Solo Air Spring, 110x15mm Boost Spacing, Maxle Lite, 51mm Offset
Rear Shock
X-Fusion O2 R, 210x50mm, Rebound Adjustment, Custom Tune, 25mm x M8 Hardware
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus SGS 10-Speed
Front Derailleur
- - -
Shift Levers
Shimano Deore 1x10-Speed
Cassette
SunRace 10-Speed, 11-42T
Crank
Marin Forged Alloy 1x10, Hollow Spindle, Steel Narrow-Wide 30T Chainring, 76mm BCD, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X10
Pedals
- - -
Wheels
Front Hub
Forged Alloy, 110x15mm, Centerlock Disc, 32H
Rear Hub
Forged Alloy, 141x9mm, Quad Sealed Bearings, Centerlock Disc, 32H, Standard Free Hub Body
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire, Crown Gem 29x2.3", Dual Control Compound, Folding Bead, Tubeless Compatible
Brakes
Brakes
Shimano BR-M315 Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano BL-M315 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 45mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Grips
Marin Dual Density
Headset
FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin, Two Bolt Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.34 mm | 1.27 mm |
| Bottom Bracket Height | 337.5 mm | 337.5 mm | 337.5 mm | 337.5 mm |
| Front Center | 702 mm | 724 mm | 746 mm | 777 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 112 mm | 111 mm | 112 mm |
| Stack | 611 mm | 616 mm | 621 mm | 625 mm |
| Reach | 422 mm | 443 mm | 462 mm | 492 mm |
| Top Tube Length | 587 mm | 614 mm | 638 mm | 672 mm |
| Seat Tube Angle | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° |
| Seat Tube Length | 385 mm | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1136 mm | 1158 mm | 1180 mm | 1211 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 686 mm | 715 mm | 727 mm | 752 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Rift Zone 1 belongs to the Marin Rift model. Marin launched 72 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Marin Rift Zone 1 2018 is the most economical model, with a starting price of 1549$. Marin Rift Zone 3 2018 on the other hand costs 2649$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Marin released this model in 2018, its price was 1549$. Comparing this to the average Trail bike price, we see that the price is 78.31% smaller.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
Rift Zone 1 has an aluminum fork, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The Rift Zone 1 has a rear shock with a travel of 120mm. The model X-Fusion O2 R is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When it comes to wheels, the Rift Zone 1 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Rift Zone 1 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
