Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork Marzocchi Bomber Z2
-
Groupset SLX, FSA -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
154cm - 164cm
SM
161cm - 172cm
MD
169cm - 179cm
LG
176cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 27.5” Wheels, 120mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Suspension Fork
Marzocchi Bomber Z2 27.5", Rail Damper with Sweep Adjustment, 130mm Travel, Kabolt Bolt-On Axle, 44mm Offset
Drivetrain
Rear Derailleur
Shimano SLX, 12-Speed, SGS
Front Derailleur
-
Shift Levers
Shimano Deore, 12-Speed, SL-7100R, I-Spec EV
Cassette
Shimano, SLX 12-Speed, 10-51T
Crank
FSA Grid, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
Bottom Bracket
Mego EXO 73mm BSA
Chain
KMC X-12 Silver and Black
Pedals
-
Wheels
Front Hub
Shimano HF-MT410B, 110x15mm, Centerlock
Rear Hub
Shimano HB-MT410B, 148x12mm, Centerlock, Microspline Freehub Body
Rims
Marin Aluminum Double Wall, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible
Tires
Maxxis Assegai, 27.5x2.5", MAXX TERAA, EXO, Tubeless Compatible
Brakes
Brake Levers
Shimano BL-M4100 Hydraulic Lever, I-Spec EV Compatible
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
TranzX, YSP23JL, 1x Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 175mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.32 mm | 1.29 mm | 1.24 mm |
| Bottom Bracket Height | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm | 338.5 mm |
| Front Center | 700 | 717 mm | 739 mm | 763 mm | 785 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 109 mm | 109 mm | 109 mm | 109 mm | 109 mm |
| Stack | 577 mm | 581.6 mm | 586.2 mm | 595.3 mm | 599.9 mm |
| Reach | 408 mm | 423 mm | 443 mm | 463 mm | 483 mm |
| Top Tube Length | 568.6 mm | 584.8 mm | 606.1 mm | 630.9 mm | 649.9 mm |
| Seat Tube Angle | 75 ° | 74.7 ° | 74.5 ° | 74.3 ° | 74.1 ° |
| Seat Tube Length | 330 mm | 380 mm | 425 mm | 470 mm | 515 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 125 mm | 130 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1127 mm | 1144 mm | 1166 mm | 1190 mm | 1212 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 645 mm | 663 mm | 700 | 725 mm | 766 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 161 cm | 169 cm | 176 cm | 184 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm | 187 cm | 193 cm |
About this model
Rift Zone 27.5 3 belongs to the Marin Rift model. Marin launched 72 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Marin Rift Zone Jr 2021 is the most affordable bike of this model and has a price of 1769$. On the other hand, Marin Rift Zone Carbon 29 2 2021, is the most expensive and costs 4379$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 2849$. Comparing the average cost of a Trail bike to this one, you will see that Rift Zone 27.5 3 price is 3.15% more expensive.
Rift Zone 27.5 3 components
Fork
This bike has the Marzocchi Bomber Z2 fork installed. The fork’s travel is 130mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the Rift Zone 27.5 3 model has 27.5″ aluminum wheels. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rift Zone 27.5 3 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Rift Zone 27.5 3 comes in 5 sizes, that range from 154 cm – 193 cm (5.05 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Marin Rift Zone 27.5 3 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
