Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Revelation RC
-
Groupset SLX, FSA -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum Frame, 29” Wheels, 120mm Travel MultiTrac Suspension Platform, Seatstay Mounted Post Mount Disc Brakes, 148x12mm Boost Thru-Axle
Suspension Fork
RockShox Revelation RC 29", 120mm Travel, Compression and Rebound Adjustment, Alloy Tapered Steerer, 110x15mm Boost Spacing, Maxle Stealth, 51mm Offset
Drivetrain
Rear Derailleur
Shimano RD-M7000, SLX GS, Direct Attachment, 11-Speed
Front Derailleur
- - -Shift Lever
Shift Levers
Shimano SL-7000R 1x11-Speed
Cassette
Shimano SLX M7000 Cassette, 11-46T
Crank
FSA V-Drive, Modular 1x, 30T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11 Extra Light
Pedals
- - -
Wheels
Front Hub
Formula, 110x15mm, Centerlock Disc, 32H
Rear Hub
Formula, 148x12mm, Quad Sealed Bearings, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Sleeved Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
WTB Trail Boss, 29x2.4", TCS Light/Fast, Tubeless Compatible
Brakes
Brakes
Shimano Deore M6000 Hydraulic Disc, 180mm Rotor
Brake Levers
Shimano Deore M6000 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 45mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 57E, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
WTB Volt Comp
Seatpost
TranzX Dropper Post, YSP15 w/ 1x Remote, Size S 100mm Travel, All Other Sizes: 120mm Travel
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.34 mm | 1.27 mm |
| Bottom Bracket Height | 337.5 mm | 337.5 mm | 337.5 mm | 337.5 mm |
| Front Center | 702 mm | 724 mm | 746 mm | 777 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 111 mm | 112 mm | 111 mm | 112 mm |
| Stack | 611 mm | 616 mm | 621 mm | 625 mm |
| Reach | 422 mm | 443 mm | 462 mm | 492 mm |
| Top Tube Length | 587 mm | 614 mm | 638 mm | 672 mm |
| Seat Tube Angle | 74.8 ° | 74.8 ° | 74.8 ° | 74.8 ° |
| Seat Tube Length | 385 mm | 420 mm | 450 mm | 480 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm | 115 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1136 mm | 1158 mm | 1180 mm | 1211 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 686 mm | 715 mm | 727 mm | 752 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rift Zone 3 belongs to the Marin Rift model. There are 72 bikes that carry this model name. Take a sneak peek at all Marin Rift bikes models from 2019, by clicking here.
Model range prices
Marin Rift Zone 1 2019 is the cheapest bike model and costs 1599$. Marin Rift Zone 3 2019 is the most expensive one and costs 2649$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Marin Rift Zone 3 price was 2649$. Comparing the average cost of a Trail bike to this one, you will see that Rift Zone 3 price is 4.27% lower.
Rift Zone 3 components
Fork
The RockShox Revelation RC is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Rift Zone 3 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Rift Zone 3 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Therefore, climbing or descending will be a breeze.
