Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 110mm -
Fork RockShox Reba
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Front Triangle w/ Alloy Swingarm, 29” Wheels, 110mm Travel IsoTrac Suspension Platform, Chainstay Mounted Post Mount Disc Brakes, 142x12mm Thru-Axle
Suspension Fork
RockShox Reba RL 29”, 120mm Travel, Compression and Rebound Adjustment, Tapered Alloy Steerer, 100x15mm Thru-Axle, 51mm Offset
Drivetrain
Rear Derailleur
Shimano RD-M7000, SLX GS, Direct Attachment
Front Derailleur
Marin Bear Claw Bottle Opener
Shift Levers
Shimano SL-7000R 11-Speed
Cassette
Sunrace 11-Speed, 11-42T
Crank
Marin Forged Alloy 1x11, Hollow CrMo Spindle, Direct Mount Narrow-Wide 32T Chainring
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X11L
Pedals
-
Wheels
Front Hub
Formula, 100x15mm, Sealed Cartridge Bearings, 6-Bolt Disc, 32H
Rear Hub
Formula, 142x12mm, Alloy Axle, Quad Cartridge Sealed Bearings, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible
Tires
F: Schwalbe Nobby Nic Performance 29
Brakes
Brakes
Magura MT4 Hydraulic Disc, 180mm Storm Rotor
Brake Levers
Magura MT4 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm width, 4º up, 9º back
Grips
Marin Single Clamp Locking
Headset
FSA Orbit, Sealed Cartridge Bearings, 1 1/8
Seat
Saddle
WTB Volt Comp SL
Seatpost
KS Dropzone Dropper Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.37 mm | 1.38 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 688 mm | 708 mm | 729 mm | 745 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 85 mm | 85 mm | 85 mm | 85 mm |
| Stack | 620.46 mm | 620.46 mm | 629.83 mm | 648.59 mm |
| Reach | 423.52 mm | 443.52 mm | 460.83 mm | 470.46 mm |
| Top Tube Length | 600 mm | 620 mm | 640 mm | 655 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 405 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.65 ° | 69.65 ° | 69.65 ° | 69.65 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1130 mm | 1150 mm | 1171 mm | 1187 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 696 mm | 707 mm | 730 mm | 768 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Rift Zone 7 is part of the Marin Rift model. There are 72 bikes that carry this model name. Check out the entire range from 2017 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Fork
The RockShox Reba is included from the factory. It has a travel distance of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The wheels on Rift Zone 7 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
