Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 110mm -
Fork Fox Performance Float 32
-
Groupset X01 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Rift Zone Carbon Monocoque Main Frame & Swing Arm, 110mm travel IsoTrac Suspension System, 29
Suspension Fork
Fox 32 Performance TALAS 29er, Tapered Alloy Steer Tube and 15QR, 120-90mm Travel
Drivetrain
Rear Derailleur
SRAM X01 Carbon Type 2, 11 Speed
Front Derailleur
None
Shift Levers
SRAM X01 Trigger Shifter, 11-Speed
Cassette
SRAM XG-1180, 10-42, 11-Speed
Crank
SRAM X01 Carbon, 32T
Bottom Bracket
SRAM GXP
Chain
SRAM PCX1, Black
Pedals
None
Wheels
Front Hub
Easton, Included with wheelset
Rear Hub
Easton, Included with wheelset
Rims
Easton Haven 29er, UST Tubeless
Tires
Schwalbe Nobby Nic Evolution Series, SnakeSkin Sidewall, Tubeless Ready, 29 x 2.25
Brakes
Brakes
SRAM Guide RS Hydraulic Disc, 7” Rotor
Brake Levers
Avid Hydraulic, Carbon
Cockpit
Stem
Easton EA70, 6 Degree
Handlebar
Easton EA70 XC, 9 Degree Sweep, 720mm Wide
Grips
Marin Micro-Knurl Double Locking
Headset
FSA Orbit 1.5 ZS, 1 1/8” Top, 1.5” Bottom
Seat
Saddle
Fizik Tundra MG
Seatpost
KS LEV Integra, 125mm Drop, Internally Routed Remote with Southpaw Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.37 mm | 1.38 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 688 mm | 708 mm | 729 mm | 745 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 85 mm | 85 mm | 85 mm | 85 mm |
| Stack | 620.46 mm | 620.46 mm | 629.83 mm | 648.59 mm |
| Reach | 423.52 mm | 443.52 mm | 460.83 mm | 470.46 mm |
| Top Tube Length | 600 mm | 620 mm | 640 mm | 655 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 405 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.65 ° | 69.65 ° | 69.65 ° | 69.65 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1130 mm | 1150 mm | 1171 mm | 1187 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 696 mm | 707 mm | 730 mm | 768 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Rift Zone 9 Carbon is part of the Marin Rift model. Marin launched 72 bikes of this model so far. Take a sneak peek at all Marin Rift bikes models from 2015, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Rift Zone 9 Carbon components
Fork
The Rift Zone 9 Carbon comes factory-installed with the Fox Performance Float 32 fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When leaving the production line, the Rift Zone 9 Carbon model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Rift Zone 9 Carbon has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Rift Zone 9 Carbon comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
Dropper post
The Marin model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
