Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox Performance Elite Float 36
-
Groupset XT -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano BT-EN806, Internal 630Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 179cm
LG
176cm - 187cm
XL
184cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
All New Series 4 Alloy Frame, 140mm MultiTrac Suspension, Integrated Battery/Charging Port, 148mm Rear Thru-Axle, Built-in Rear Speed Sensor
Suspension Fork
Fox 36 Performance Elite, 140mm travel, 29", 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fender
Rear Shock
Fox Float X, Performance Elite Series, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x50mm, M8x30mm Top, M8x25mm Bottom
Drivetrain
Rear Derailleur
Shimano, Deore XT RD-M8130, 11-Speed, SGS, LinkGlide
Shift Levers
Shimano Deore XT SL-M8130-R, LinkGlide
Cassette
Shimano XT LinkGlide LG-600, 11-Speed, 11-50T
Crank
Shimano XT M8150, 160mm Length, 38t Chainring
Bottom Bracket
BSA, 73mm, threaded
Chain
KMC E-11S
Pedals
Marin MTB Plastic
Wheels
Front Hub
Shimano MT-410B, 110x15mm, Centerlock Disc, 32H
Rear Hub
Shimano HB-MT510B, 148x12mm, Centerlock Disc, Micro Spline Freehub Body
Rims
Marin Aluminum Double Wall, 29" Diameter, 29mm Inner Rim Width, Sleeved Joint, Disc Specific, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire Co. Attack HPL, 29x2.5", Top 40 Tubeless Compatible, Override E-Specific Casing
Brakes
Brakes
TRP DH-R EVO, 4-Piston Hydraulic Disc, Brake 203mm Rotor
Brake Levers
TRP DH-R Evo
Cockpit
Stem
Marin CNC, 35mm Length, 35mm Bar Bore
Handlebar
Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back
Grips
Marin Grizzly Lock On
Headset
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin eMTB Saddle
Seatpost
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm
Motor & Battery
Motor
Shimano Steps EP801 Drive Unit, 250W, 85Nm
Battery
Shimano BT-EN806, Internal 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.36 mm | 1.32 mm | 1.28 mm | 1.23 mm |
| Bottom Bracket Height | 348.5 mm | 348.5 mm | 348.5 mm | 348.5 mm |
| Front Center | 760 mm | 784 mm | 809 mm | 843 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 128 mm | 127 mm | 128 mm | 128 mm |
| Stack | 613.98 mm | 621.04 mm | 632.1 mm | 641.16 mm |
| Reach | 452 mm | 472 mm | 492 mm | 522 mm |
| Top Tube Length | 592.13 mm | 614.22 mm | 636.32 mm | 668.41 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 390 mm | 400 mm | 425 mm | 435 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1205 mm | 1229 mm | 1253 mm | 1287 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 700 | 703 mm | 716 mm | 726 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 176 cm | 184 cm |
| Rider Max Height | 169 cm | 179 cm | 187 cm | 193 cm |
About this model
Rift Zone E2 is part of the Marin E Rift model. Marin launched 6 e-bikes of this model so far. Take a sneak peek at all Marin E Rift e-bikes models from 2023, by clicking here.
Model range prices
Marin Rift Zone E 2023 is the cheapest e-bike model and costs 4499$. Marin Rift Zone E2 2023 is the most expensive one and costs 6299$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail e-bikes average price
According to our math, the average price for a trustworthy Trail e-bike is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When Marin released this model in 2023, its price was 6299$. In conclusion, this e-bike price is 87.19% more expensive than the price of the average Trail e-bike.
Overview of components
Fork
The Fox Performance Elite Float 36 is included from the factory. It has a travel distance of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Rift Zone E2 has a rear shock with a travel of 140mm. The model Fox Float X is the one installed in this e-bike. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Rift Zone E2 are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Marin Rift Zone E2 e-bike has 4 sizes, in the range of 160 cm – 193 cm (5.25 ft – 6.33 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Marin Rift Zone E2 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
