Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 130mm -
Travel Rear 130mm -
Fork X-Fusion VELVET
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
124cm - 144cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, 24” Wheels (fits up to 26"), 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Suspension Fork
X-Fusion Velvet RLC 26", 130mm Travel, Compression and Rebound Adjustment, 100x15mm Thru-Axle
Drivetrain
Rear Derailleur
Shimano Deore, 11-Speed, SGS
Front Derailleur
-
Shift Levers
Shimano Deore, 11-Speed, SL-5100R
Cassette
SunRace, 11-Speed, 11-51T, ED Black
Crank
Marin Forged Alloy 1x11, Hollow Spindle, Steel Narrow Wide 32T Chainring, Direct Mount Type
Bottom Bracket
External Sealed Cartridge Bearings
Chain
KMC X-11 Silver and Black
Wheels
Front Hub
Shimano HB-TC500, 100x15mm, Centerlock, 32H
Rear Hub
Forged Alloy, 141mm, Quad Sealed Bearings, Centerlock Disc, 32H
Rims
Marin, Double Wall Alloy, 27mm Inner, Pinned Joint, Disc Specific
Tires
Vee Tire Co. Flow Snap 24x2.4", Tackee Compound, Wire Bead
Brakes
Brakes
Hydraulic Disc
Brake Levers
Tektro HD-M280
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 15mm Rise, 720mm Width, 4º Up, 9º Back
Grips
Marin Dual Density
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.415 mm |
| Bottom Bracket Height | 308.5 mm |
| Front Center | 664 mm |
| Rake | 42 mm |
| Stack | 537.57 mm |
| Reach | 380 mm |
| Top Tube Length | 515.17 mm |
| Seat Tube Angle | 76 ° |
| Seat Tube Length | 315 mm |
| Head Tube Angle | 65.5 ° |
| Head Tube Length | 95 mm |
| Chainstay Length | 425 mm |
| Wheelbase | 1089 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 614 mm |
| Wheels | 24" |
| Rider Min Height | 124 cm |
| Rider Max Height | 144 cm |
Model Overview
Rift Zone Jr 24″ belongs to the Marin Rift model. 72 bikes variations carry this model name so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Marin Rift Zone Jr 24″ 2024 is the most economical model, with a starting price of 1699$. Marin Rift Zone 29″ 2 2024 on the other hand costs 2299$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Mountain bikes average price
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Marin released this model in 2024, its price was 1699$. In conclusion, this bike price is 175.81% more expensive than the price of the average Mountain bike.
Overview of components
Fork
Marin Rift Zone Jr 24″ 2024 bike is equipped with the X-Fusion VELVET fork, and has 130mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
When it comes to wheels, the Rift Zone Jr 24″ bike is equipped with the 24″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Rift Zone Jr 24″ comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike has one size only, so it might not fit you. In short, make sure you double-check if it fits you.
