Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Rear 110mm -
Fork RockShox Pike RCT3 -
Groupset X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Frame and Swingarm, 29” Wheels, 110mm Travel IsoTrac Suspension Platform, Chainstay Mounted Post Mount Brakes, 142x12mm Thru-Axle
Suspension Fork
RockShox Pike RCT3 29
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Front Derailleur
Marin Bear Claw Bottle Opener
Shift Levers
SRAM X01 Eagle 1x12 Speed
Cassette
SRAM XG 1295 12-Speed, X01 Eagle, 10-50T
Crank
SRAM X01 Carbon, Direct Mount 34T Eagle Chainring
Bottom Bracket
SRAM GXP BSA
Chain
SRAM X01 Eagle 12-Speed
Pedals
-
Wheels
Front Hub
Stan's NoTubes Flow MRK3 Pro Wheelset, 100x15mm, 6-Bolt
Rear Hub
Stan's NoTubes Flow MRK3 Pro Wheelset, 12x142mm, 6-Bolt
Rims
Stan's NoTubes Flow MRK3 Pro Wheelset, 30mm inner
Tires
F: WTB Trail Boss, 29”x2.25” R: WTB Nine Line, 29x2.25”, Folding Bead, Tubeless Compatible
Brakes
Brakes
SRAM Guide RS Hydraulic Disc, 180mm Rotors
Brake Levers
SRAM Guide RS
Cockpit
Stem
Gamut Cillos 3D Forged Alloy
Handlebar
Deity DC31 Mohawk Carbon
Grips
Marin Locking
Headset
FSA Orbit, Sealed Cartridge Bearings, 1 1/8
Seat
Saddle
WTB Volt Race
Seatpost
KS LEV Integra Dropper Post, Southpaw Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.37 mm | 1.38 mm |
| Bottom Bracket Height | 333 mm | 333 mm | 333 mm | 333 mm |
| Front Center | 688 mm | 708 mm | 729 mm | 745 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 85 mm | 85 mm | 85 mm | 85 mm |
| Stack | 620.46 mm | 620.46 mm | 629.83 mm | 648.59 mm |
| Reach | 423.52 mm | 443.52 mm | 460.83 mm | 470.46 mm |
| Top Tube Length | 600 mm | 620 mm | 640 mm | 655 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 405 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 69.65 ° | 69.65 ° | 69.65 ° | 69.65 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 140 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1130 mm | 1150 mm | 1171 mm | 1187 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 696 mm | 707 mm | 730 mm | 768 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Rift Zone Pro is part of the Marin Rift model. 72 bikes variations carry this model name so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Rift Zone Pro components
Fork
The fork installed on this bike is the RockShox Pike RCT3 model. The travel on this model is mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When leaving the production line, the Rift Zone Pro model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Rift Zone Pro. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
