Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Altus, Tourney -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
149cm - 157cm
MD
160cm - 169cm
LG
166cm - 177cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 Dual Sport, 6061 Aluminum, 700C Wheels, Women's Fit Geometry, Step Through Design, Disc Brake
Suspension Fork
SR Suntour NEX Disc HLO, 63mm Travel, Hydraulic Lockout, Preload Adjustment
Drivetrain
Rear Derailleur
Shimano Altus 8-Speed
Front Derailleur
Shimano FD-TY710
Shift Levers
Shimano EF505 3x8-Speed
Cassette
SunRace 8-Speed, 11-32T
Crank
Forged aluminum, 48/38/28T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z7
Pedals
Dual Sport Platform
Wheels
Front Hub
Forged Aluminum Alloy, Centerlock Disc, 32H
Rear Hub
Forged Aluminum Alloy, Centerlock Disc, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Spokes
14g Black Stainless Steel
Tires
Vee Tire, Rail, 700x40, Wire Bead
Brakes
Brakes
Shimano BR-M200 Hydraulic Disc, 160mm Rotor
Brake Levers
Shimano EF-505 Hydraulic
Cockpit
Stem
Marin Alloy
Handlebar
Marin Alloy Riser
Grips
Marin Ergonomic Locking
Headset
FSA No.10-P
Seat
Saddle
Marin Women's Fitness
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.59 mm | 1.58 mm |
| Bottom Bracket Height | 291 mm | 291 mm | 291 mm |
| Front Center | 616 mm | 615 mm | 625 mm |
| Rake | 41 mm | 41 mm | 41 mm |
| Trail | 80 mm | 80 mm | 80 mm |
| Stack | 586.99 mm | 596.41 mm | 605.85 mm |
| Reach | 380.43 mm | 375.94 mm | 382.26 mm |
| Top Tube Length | 554.9 mm | 558.9 mm | 568.1 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1052 mm | 1051 mm | 1060 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 622 mm | 668 mm | 713 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 149 cm | 160 cm | 166 cm |
| Rider Max Height | 157 cm | 169 cm | 177 cm |
Model Overview
San Anselmo DS2 completes the Marin San Anselmo model. 27 bikes variations carry this model name so far. Check out the entire range from 2020 of this model, by clicking this link.
Model range prices
Marin San Anselmo DS1 2020 is the cheapest bike model and costs 519$. Marin San Anselmo DS2 2020 is the most expensive one and costs 629$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter bikes
According to our math, the average price for a trustworthy Commuter bike is 762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 629$. Comparing this to the average Commuter bike price, we see that the price is 21.14% lower.
San Anselmo DS2 components
Fork
The SunTour NEX is included from the factory. It has a travel distance of 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When it comes to wheels, the San Anselmo DS2 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin San Anselmo DS2 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 3 sizes available for this model. Rider height can be anywhere between 149 cm – 177 cm (4.89 ft – 5.81 ft). In short, you can easily find one that suits you.
