Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 167cm
MD
164cm - 174cm
LG
171cm - 182cm
XL
179cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, Double Butted Frame, 141mm Open Dropout, 73mm Threaded BB
Suspension Fork
SR Suntour XCM32 Boost 15x110mm Spacing, 120mm Travel, Lock Out, 27.5", Bolt-On Thru-Axle, 47mm offset
Drivetrain
Rear Derailleur
MicroShift RD-M9195M, 9 Speed, With Clutch
Front Derailleur
-
Shift Levers
MicroShift SL-M9195-R, 1x9 with Bearings
Cassette
Sunrace, 9 Speed, 11-46T
Crank
Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing
Bottom Bracket
Sealed Cartridge Bearing, Square Taper
Chain
KMC X-9
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 110x15mm, Disc, 32H
Rear Hub
Forged Alloy, 141mm Width, Disc, 32H, Shimano Standard Freehub Body
Rims
Marin, Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H Tubeless Compatible
Tires
Vee Tire Co, Flow Snap, 27.5x2.6", MPC Compound, Wire Bead
Brakes
Brake Levers
Tektro M275 Hydraulic Disc
Cockpit
Stem
Marin 3D Forged Alloy, 45mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
Grips
Marin MTN, Closed End
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 317 mm | 317 mm | 317 mm | 317 mm |
| Front Center | 724 mm | 749 mm | 773 mm | 795 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 115 mm | 115 mm | 115 mm | 115 mm |
| Stack | 588.1 mm | 592.7 mm | 601.7 mm | 606.3 mm |
| Reach | 424 mm | 446 mm | 466 mm | 486 mm |
| Top Tube Length | 581.1 mm | 604.3 mm | 626.7 mm | 647.9 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 385 mm | 430 mm | 475 mm | 515 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 125 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1146 mm | 1170 mm | 1195 mm | 1217 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 666 mm | 679 mm | 716 mm | 747 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 157 cm | 164 cm | 171 cm | 179 cm |
| Rider Max Height | 167 cm | 174 cm | 182 cm | 188 cm |
About this model
San Quentin 1 is part of the Marin San Quentin model. Marin released 47 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
The most economical model, the Marin San Quentin 20 2021 has a starting price of 689$. Marin San Quentin 3 2021 on the other hand is the most expensive at 2239$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Marin released this model in 2021, its price was 999$. If we compare this with the average Trail bike cost we notice that the price is 176.48% smaller.
San Quentin 1 components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
The wheels on San Quentin 1 are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin San Quentin 1 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 157 cm – 188 cm (5.15 ft – 6.17 ft). In conclusion, you won’t have a problem finding one that suits you.
