Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 80mm -
Fork SunTour XCM
-
Groupset Altus, microSHIFT -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
111cm - 132cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, 20” Wheels, Disc Specific, 135mm Dropouts
Suspension Fork
SR Suntour XCM 24 BOOST, 80mm Travel, 110mm Axle Spacing
Drivetrain
Rear Derailleur
Shimano Altus
Front Derailleur
-
Shift Levers
MicroSHIFT TS39, 8-Speed, Thumb-Tap
Cassette
Shimano 8-speed, 11-32T
Crank
Forged Alloy, Narrow Wide 30T, 140mm
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X8
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Forged Aluminum, 32H, Disc Specific
Rear Hub
Forged Aluminum, 32H, Disc Specific
Rims
Marin, Double Wall Alloy, 25mm Internal
Tires
Vee Tire Crown Gem, 20x2.6”, Wire Bead
Brakes
Brake Levers
Tektro Kid's Specific Short Reach Lever for Hydraulic Brake
Cockpit
Stem
Marin Alloy, 35mm
Handlebar
Marin Riser, 31.8 clamp, 30mm Rise, 590mm Width
Grips
Marin MTB
Headset
FSA No. 57E
Seat
Saddle
Marin Kids MTB
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.64 mm |
| Bottom Bracket Height | 259 mm |
| Front Center | 573 mm |
| Rake | 40 mm |
| Stack | 495.5 mm |
| Reach | 303 mm |
| Top Tube Length | 437.6 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 308 mm |
| Head Tube Angle | 65 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 333 mm |
| Wheelbase | 905 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 527 mm |
| Wheels | 20" |
| Rider Min Height | 111 cm |
| Rider Max Height | 132 cm |
About this model
San Quentin 20 completes the Marin San Quentin model. There are 47 bikes that carry this model name. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Marin San Quentin 20 2022 is the cheapest bike model and costs 749$. Marin San Quentin 3 2022 is the most expensive one and costs 2399$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Mountain bikes average price
If you want to purchase a solid Mountain bike, it is important to know that the average cost is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 749$. If we compare this with the average Mountain bike cost we notice that the price is 21.59% more expensive.
Overview of components
Fork
The SunTour XCM is included from the factory. It has a travel distance of 80mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the San Quentin 20 model has 20″ aluminum wheels. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The San Quentin 20 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Marin San Quentin 20 2022 is available in one size only. In conclusion, double-check its size to make sure it’s a good fit for you.
