Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset microSHIFT Advent -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
One Size
124cm - 142cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 2 6061 Aluminum, 24” Wheels, Disc Specific, 135mm Dropouts
Suspension Fork
RockShox Judy Silver TK, 100mm Travel, Solo Air, 110x15mm Maxle Stealth
Drivetrain
Rear Derailleur
microSHIFT Advent 9-Speed
Front Derailleur
-
Shift Levers
microSHIFT Advent 9-Speed
Cassette
microSHIFT 9-Speed, 11-46T
Crank
Forged Alloy, Narrow Wide 30T, 152mm
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Kids Specific Nylon Pedal
Wheels
Front Hub
Forged Aluminum, 32H, Disc Specific
Rear Hub
Forged Aluminum, 32H, Disc Specific
Rims
Marin, Double Wall Alloy, 27mm Internal
Tires
Vee Tire Co. Crown Gem, 24”x2.6”, Wire Bead
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano Hydraulic
Cockpit
Stem
Marin Alloy, 35mm
Handlebar
Marin Riser, 31.8 clamp, 30mm Rise, 590mm Width
Grips
Marin MTB
Headset
FSA No. 57E
Seat
Saddle
Marin Kids MTB
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.56 mm |
| Bottom Bracket Height | 290 mm |
| Front Center | 661 mm |
| Rake | 42 mm |
| Stack | 546.5 mm |
| Reach | 351 mm |
| Top Tube Length | 495.8 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 321 mm |
| Head Tube Angle | 65 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 375 mm |
| Wheelbase | 1035 mm |
| Bottom Bracket Drop | 30 mm |
| Standover Height | 582 mm |
| Wheels | 24" |
| Rider Min Height | 124 cm |
| Rider Max Height | 142 cm |
Model Overview
San Quentin 24″ is a Marin San Quentin model. There are 47 bikes that carry this model name. Take a sneak peek at all Marin San Quentin bikes models from 2023, by clicking here.
Model range prices
Marin San Quentin 20″ 2023 is the most economical model, with a starting price of 699$. Marin San Quentin 27.5″ 3 2023 on the other hand costs 1843$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Mountain bikes
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Marin released this model in 2023, its price was 1099$. If we compare this with the average Mountain bike cost we notice that the price is 78.41% higher.
San Quentin 24″ components
Fork
The RockShox Judy Silver TK is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The San Quentin 24″ 2023 bike is equipped with 24″ aluminum wheels when leaving the factory. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin San Quentin 24″ has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
