Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Fork RockShox Revelation RC
-
Groupset SLX, FSA -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 167cm
MD
164cm - 174cm
LG
171cm - 179cm
XL
176cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 6061 Aluminum, Double Butted Frame, Internal Shifter & Dropper Post Routing, External Brake, 12x148mm Thru Axle, 73mm Threaded BB
Suspension Fork
RockShox Revelation RC, 110x15mm Boost Spacing, Fast Black Stanchions, 130mm Travel, Bolt-On Thru Axle
Rear Shock
---
Drivetrain
Rear Derailleur
Shimano RD-M7000, SLX GS, Direct Mount, 11-Speed
Front Derailleur
-
Shift Levers
Shimano SL-7000R 11-Speed
Cassette
SunRace, 11-Speed, 11-46T
Crank
FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
Bottom Bracket
External Sealed Cartridge Bearing
Chain
KMC X-11 EL
Chain Guide
---
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, 110x15mm, Sealed Cartridge Bearing, Centerlock Disc, 32H
Rear Hub
Forged Alloy, Quad Sealed Cartridge Bearings, Alloy Axle, 12x148mm, Centerlock Disc, 32H, Shimano Standard Freehub Body
Rims
Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Pinned Joint, 32H, Tubeless Compatible
Spokes
14g Black Stainless Steel
Tires
Vee Tire Flow Snap, 27.5x2.6”, Tackee Compound, Folding Bead, Tubeless Compatible
Brakes
Brakes
Shimano BR-MT400 Hydraulic Disc,180mm Centerlock Rotor
Brake Levers
Shimano BL-MT400 Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm rise, 5º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, All Other Sizes: 150mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.33 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 724 mm | 749 mm | 773 mm | 795 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 115 mm | 115 mm | 115 mm | 115 mm |
| Stack | 588.1 mm | 592.7 mm | 601.7 mm | 606.3 mm |
| Reach | 424 mm | 446 mm | 466 mm | 486 mm |
| Top Tube Length | 581.1 mm | 604.3 mm | 626.7 mm | 647.9 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 385 mm | 430 mm | 475 mm | 515 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 125 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1146 mm | 1170 mm | 1195 mm | 1217 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 666 mm | 679 mm | 716 mm | 747 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 157 cm | 164 cm | 171 cm | 176 cm |
| Rider Max Height | 167 cm | 174 cm | 179 cm | 182 cm |
Model Overview
San Quentin 3 completes the Marin San Quentin model. 47 bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Marin San Quentin 1 2019 is the cheapest bike model and costs 899$. Marin San Quentin 3 2019 is the most expensive one and costs 1999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2019 for 1999$. Comparing this to the average Trail bike price, we see that the price is 38.17% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
San Quentin 3 components
Fork
Marin San Quentin 3 2019 bike is equipped with the RockShox Revelation RC fork, and has 130mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The wheels on San Quentin 3 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The San Quentin 3 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 157 cm – 182 cm (5.15 ft – 5.97 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the San Quentin 3. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
