Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NVX
-
Groupset Deore -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano BTEN605, 504Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 169cm
MD
166cm - 179cm
LG
176cm - 189cm
XL
187cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Butted and Formed 6061 Aluminum, 650B Wheel, Forged Motor Mount, Hydroformed Downtube Battery Mount, Integrated Wiring, Internal Housing, Kickstand, Rack, and Fender Mounts
Suspension Fork
SR/Suntour NVX-E, 63mm Travel, Disc Specific
Drivetrain
Rear Derailleur
Shimano Deore 11-Speed
Shift Levers
Shimano Deore 11-Speed
Cassette
Shimano Deore 11-Speed 11-51T
Crank
Forged Aluminum w/ 44T Steel Chairing
Bottom Bracket
-
Chain
KMC E11S
Pedals
Nylon Platform
Wheels
Front Hub
Forged Alloy, Disc Specific, 32H
Rear Hub
Forged Alloy, Disc Specific, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Spokes
14g Black Stainless Steel
Tires
WTB Horizon, 650Bx47, Wire Bead
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano MT201 Hydraulic
Cockpit
Stem
Marin Alloy
Handlebar
Marin Mini Riser Alloy
Grips
Marin County
Headset
FSA No. 57E
Seat
Saddle
Marin City Plush
Seatpost
Marin Alloy, 30.9mm
Motor & Battery
Motor
Shimano Steps EP6 Drive Unit, 250W, 85Nm, USA Class 3 (28mph, 45km/h), Australia, Canada, EU and UK 25km/h
Battery
Shimano BTEN605, 504Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.53 mm | 1.52 mm | 1.54 mm |
| Bottom Bracket Height | 296.5 mm | 296.5 mm | 296.5 mm | 296.5 mm |
| Front Center | 632 mm | 668 mm | 698 mm | 724 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 76 mm | 76 mm | 76 mm | 76 mm |
| Stack | 586 mm | 613.7 mm | 641.8 mm | 669.9 mm |
| Reach | 376 mm | 401 mm | 421 mm | 436 mm |
| Top Tube Length | 545 mm | 578 mm | 606.2 mm | 629.2 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 480 mm | 520 mm | 558 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 120 mm | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1079 mm | 1114 mm | 1145 mm | 1170 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 675 mm | 713 mm | 743 mm | 780 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 157 cm | 166 cm | 176 cm | 187 cm |
| Rider Max Height | 169 cm | 179 cm | 189 cm | 193 cm |
About this model
Sausalito E2 completes the Marin E Sausalito model. Marin released 12 e-bikes variations of this model so far. Take a sneak peek at all Marin E Sausalito e-bikes models from 2023, by clicking here.
Model range prices
Marin Sausalito ST E1 2023 is the cheapest e-bike model and costs 2399$. Marin Sausalito E2 2023 is the most expensive one and costs 2999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Urban e-bikes
According to our calculations, the average cost of a General Urban e-bike that is reliable is 2098$. However, you could also get a good General Urban e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
When Marin released this model in 2023, its price was 2999$. Comparing this to the average General Urban e-bike price, we see that the price is 42.95% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Sausalito E2 components
Fork
Marin Sausalito E2 2023 e-bike is equipped with the Suntour NVX fork, and has 63mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The Sausalito E2 2023 e-bike is equipped with aluminum wheels when leaving the factory. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Sausalito E2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Sausalito E2 comes in 4 sizes, that range from 157 cm – 193 cm (5.15 ft – 6.33 ft). In short, it won’t be difficult to find the right one for you.
