Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
T3 Unidirectional Carbon with Internal Cable Routing, Power Taper Seat Tube and 1 1/8” to 1.5” Tapered Headtube, PF30 Bottom Bracket
Suspension Fork
CXR-SL Carbon with Tapered Carbon Steerer
Drivetrain
Bottom Bracket
PF30, press-fit
Cockpit
Headset
FSA Orbit C-40 with Cartridge Bearings
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 269 mm | 269 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 576 mm | 581 mm | 585 mm | 596 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 507.3 mm | 535 mm | 550 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 105 mm | 120 mm | 145 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 976 mm | 981 mm | 985 mm | 996 mm | 1005 mm | 1015 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 733 mm | 755 mm | 782 mm | 800 mm | 818 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Stelvio Frame Set is part of the Marin Stelvio model. There are 7 frames that carry this model name. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
General Road frames average price
Our math shows that the average cost of a dependable General Road frame is 2445$. However, this doesn’t mean that if you spend less money on a General Road frame, you couldn’t get a decent one. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Stelvio Frame Set components
Fork material
The fork on this frame is made out of carbon, so, it won’t add up to much weight to your frame. However, the price you have to pay for a carbon fork is considerably higher.
