Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 700c -
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 11 Electronic -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
T3 Unidirectional Carbon with Internal Cable Routing, Power Taper Seat Tube and 1 1/8” to 1.5” Tapered Headtube, PF30 Bottom Bracket
Suspension Fork
CXR-SL Carbon with Tapered Carbon Steerer
Drivetrain
Rear Derailleur
Shimano Ultegra Di2
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano Ultegra Di2, 11 Speed
Cassette
Shimano Ultegra, 11-28, 11 Speed
Crank
Shimano Ultegra, 52/36T
Bottom Bracket
FSA Sealed Cartridge PressFit30 with Shimano Adapter
Chain
Shimano Ultegra
Pedals
None
Wheels
Front Hub
Mavic Ksyrium Elite
Rear Hub
Mavic Ksyrium Elite
Rims
Mavic Ksyrium Elite WTS
Tires
Mavic WTS Yksion 700 x 23c Folding Bead Tires
Brakes
Brakes
Shimano Ultegra
Brake Levers
Shimano with Integrated Shifters
Cockpit
Stem
Ritchey WCS 4-Axis 44 Threadless. 84/-6 Deg Rise
Handlebar
Ritchey WCS Evo-Curve, 4 degree sweep, shallow drop
Grips
Marin Road Plus Tape
Headset
FSA Orbit C-40 with Cartridge Bearings
Seat
Saddle
Prologo Scratch Pro with T2.0 Rails
Seatpost
Ritchey WCS 1 Bolt w/Di2 Battery Mount. 25mm offset, 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 269 mm | 269 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 576 mm | 581 mm | 585 mm | 596 mm | 605 mm | 615 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 507.3 mm | 535 mm | 550 mm | 565 mm | 580 mm | 595 mm |
| Seat Tube Angle | 75 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 105 mm | 120 mm | 145 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 976 mm | 981 mm | 985 mm | 996 mm | 1005 mm | 1015 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 733 mm | 755 mm | 782 mm | 800 mm | 818 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Stelvio Pro Ultegra Di2 belongs to the Marin Stelvio model. Marin launched 7 bikes of this model so far. Take a sneak peek at all Marin Stelvio bikes models from 2015, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
General Road bikes average price
According to our math, the average price for a trustworthy General Road bike is 1915$. However, you could also get a good General Road bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on Stelvio Pro Ultegra Di2 are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
