Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset microSHIFT Advent -
Suspension Rigid -
Drivetrain 1 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 174cm
LG
171cm - 182cm
XL
179cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Disc Specific, Comfort Control Geometry, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Straight Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
microSHIFT Advent 9-Speed Wide Range
Front Derailleur
-
Shift Levers
microSHIFT Advent 9-Speed
Cassette
microSHIFT 9-Speed 11-46T
Crank
Alloy Crank, Steel 38T Chainring, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC X9
Pedals
Marin Comfort Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire Co. Speedster, 27.5”x2.35”, Puncture Protection
Brakes
Brakes
Mechanical Disc
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy, 31.8mm Clamp
Handlebar
Marin Alloy, 60mm Rise, 30? Backsweep
Grips
Marin County
Headset
FSA, TH No.10P
Seat
Saddle
Marin Comfort
Seatpost
Marin Alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.85 mm | 1.82 mm | 1.8 mm | 1.78 mm |
| Bottom Bracket Height | 276.5 mm | 276.5 mm | 276.5 mm | 276.5 mm |
| Front Center | 608 mm | 630 mm | 652 mm | 669 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 627.2 mm | 645.9 mm | 664.5 mm | 678.4 mm |
| Reach | 339 mm | 354 mm | 369 mm | 380.6 mm |
| Top Tube Length | 605.7 mm | 628.6 mm | 651.5 mm | 669 mm |
| Seat Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Seat Tube Length | 382 mm | 406 mm | 444 mm | 470 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 210 mm | 230 mm | 250 mm | 265 mm |
| Chainstay Length | 484 mm | 484 mm | 484 mm | 484 mm |
| Wheelbase | 1082 mm | 1105 mm | 1127 mm | 1144 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 617 mm | 617 mm | 673 mm | 674 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 164 cm | 171 cm | 179 cm |
| Rider Max Height | 167 cm | 174 cm | 182 cm | 188 cm |
About this model
Stinson 2 is part of the Marin Stinson model. Marin released 34 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Marin Stinson ST 1 2023 is the most economical model, with a starting price of 599$. Marin Stinson 2 2023 on the other hand costs 699$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid bikes average price
If you want an acceptable Hybrid bike you should know that the average price is 562$. However, even though the average price of a Hybrid bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Marin released this model in 2023, its price was 699$. In conclusion, this bike price is 24.38% higher than the price of the average Hybrid bike.
Stinson 2 components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels size
The wheels on Stinson 2 are the aluminum type. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Stinson 2 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 152 cm – 188 cm (4.99 ft – 6.17 ft). In short, it won’t be difficult to find the right one for you.
