Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 63mm -
Fork SunTour
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Rim
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 6061 Aluminum, 26” Wheels, Comfort Control Geometry
Suspension Fork
SR Suntour, Preload Adjustment, 63mm Travel
Drivetrain
Rear Derailleur
Shimano Acera Shadow
Front Derailleur
Shimano FD-M190
Shift Levers
Shimano EF51 8-Speed
Cassette
Sunrace 8-Speed, 11-32T
Crank
Forged Alloy, 42/34/24T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearing, Square Taper
Chain
KMC Z8
Pedals
Ergonomic Platform Pedal, Kraton Top Grip
Wheels
Front Hub
Formula, 32H
Rear Hub
Formula, 32H
Rims
Maddux Double Wall, Machined Sidewall
Tires
Schwalbe Land Cruiser, 26x1.95”, Kevlar Puncture Protection
Brakes
Brakes
Forged Alloy Linear Pull w/ Power Modulator
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Adjustable Angle
Handlebar
Marin Riser
Grips
Marin Ergonomic Locking
Headset
FSA, Threaded
Seat
Saddle
Marin Comfort
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Front Center | 588 mm | 603 mm | 617 mm | 631 mm | 645 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Top Tube Length | 588 mm | 603 mm | 618 mm | 633 mm | 648 mm |
| Seat Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Seat Tube Length | 381 mm | 431.8 mm | 482.6 mm | 520.7 mm | 558.8 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 160 mm | 170 mm | 185 mm | 200 mm | 215 mm |
| Chainstay Length | 483 mm | 483 mm | 483 mm | 483 mm | 483 mm |
| Wheelbase | 1064 mm | 1078 mm | 1093 mm | 1107 mm | 1121 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Stinson is a Marin Stinson model. Marin launched 34 bikes of this model so far. You can easily view all of the Marin Stinson bikes models from 2016, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Comfort bikes average price
Our math shows that the average cost of a dependable Comfort bike is 360$. However, even though the average price of a Comfort bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Stinson components
Fork
The SunTour is included from the factory. It has a travel distance of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
The wheels on Stinson are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Stinson is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
