Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Tourney, Shimano -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
152cm - 165cm
MD
165cm - 172cm
LG
172cm - 180cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Comfort Control Geometry, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Straight Blade, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
Shimano TY700
Shift Levers
Shimano EF41, 3x7-Speed
Cassette
SunRace 7-Speed, 11-32T
Crank
Shimano FC-TY301, 42/34/24T, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z50
Pedals
Marin Comfort Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Machined Sidewall
Spokes
14g Stainless Steel
Tires
Vee Tire Co. Speedster, 27.5”x2.0”, Puncture Protection
Brakes
Brakes
Forged Alloy Linear Pull w/ Power Modulator
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Adjustable Height and Angle
Handlebar
Marin Alloy, 50mm Rise
Grips
Marin Ergonomic Locking
Headset
FSA, Threaded
Seat
Saddle
Marin Comfort
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 2.02 mm | 2.03 mm | 2.02 mm | 2.01 mm | 2.03 mm |
| Bottom Bracket Height | 277 mm | 277 mm | 277 mm | 277 mm | 277 mm |
| Front Center | 579 mm | 593 mm | 607 mm | 621 mm | 635 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 625.73 mm | 644.34 mm | 658.3 mm | 672.25 mm | 690.86 mm |
| Reach | 309.96 mm | 316.68 mm | 325.46 mm | 334.25 mm | 340.96 mm |
| Top Tube Length | 589 mm | 604 mm | 619 mm | 634 mm | 649 mm |
| Seat Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Seat Tube Length | 382 mm | 432 mm | 483 mm | 503 mm | 559 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 210 mm | 230 mm | 245 mm | 260 mm | 280 mm |
| Chainstay Length | 489 mm | 489 mm | 489 mm | 489 mm | 489 mm |
| Wheelbase | 1059 mm | 1073 mm | 1088 mm | 1102 mm | 1116 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 690 mm | 730 mm | 771 mm | 788 mm | 832 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 165 cm | 172 cm | cm | cm |
| Rider Max Height | 165 cm | 172 cm | 180 cm | cm | cm |
Model Overview
Stinson belongs to the Marin Stinson model. Marin launched 34 bikes of this model so far. You can easily view all of the Marin Stinson bikes models from 2019, here.
Model range prices
Marin Stinson 7 ST 2019 is the cheapest bike model and costs 419$. Marin Stinson 2019 is the most expensive one and costs 469$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Comfort bikes average price
According to our math, the average price for a trustworthy Comfort bike is 360$. However, even if your budget is less than the average, you might still be able to get a top-quality Comfort bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2019 and its price was 469$. Doing a quick comparison, we notice that Stinson price is 30.28% more expensive than the average cost of a Comfort bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The Stinson 2019 bike is equipped with aluminum wheels when leaving the factory. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Stinson comes with Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, you could spend a little extra and get a bike that has hydraulic brakes.
