Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Tourney, Altus -
Suspension Rigid -
Motor 250W hub-drive -
Battery 309Wh, 36V, Rear Carrier Mounted -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 174cm
LG
171cm - 182cm
XL
179cm - 188cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Comfort, eBike-Specific, 6061 Aluminum, 27.5” Wheels, Disc Specific, Comfort Control Geometry, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Straight Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
-
Shift Levers
Shimano Altus 7-Speed RapidFire
Cassette
Shimano 7-Speed Freewheel, 14-34T
Crank
Alloy Crank, Steel 38T Chainring, Ring Guard
Bottom Bracket
Integrated Torque Sensing, Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Marin Comfort Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
250 Watt Hub Motor, 36H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire Co. Speedster, 27.5”x2.35”, Puncture Protection
Brakes
Brakes
Mechanical Disc
Brake Levers
Alloy, Long Pull
Cockpit
Stem
Marin Alloy
Handlebar
Marin Alloy, 25mm Rise, 18? Backsweep
Grips
Marin County
Headset
FSA, TH No.10P
Seat
Saddle
Marin Comfort
Seatpost
Marin Alloy, 30.9mm
Motor & Battery
Motor
250 Watt Hub Motor, 36H
Battery
309Wh, 36V, Rear Carrier Mounted
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.85 mm | 1.82 mm | 1.8 mm | 1.78 mm |
| Bottom Bracket Height | 276.5 mm | 276.5 mm | 276.5 mm | 276.5 mm |
| Front Center | 608 mm | 629 mm | 652 mm | 669 mm |
| Rake | 40 mm | 40 mm | 40 mm | 40 mm |
| Trail | 87 mm | 87 mm | 87 mm | 87 mm |
| Stack | 627.2 mm | 645.9 mm | 664.5 mm | 678.4 mm |
| Reach | 339 mm | 354 mm | 369 mm | 380.6 mm |
| Top Tube Length | 605.7 mm | 628.6 mm | 651.5 mm | 669 mm |
| Seat Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Seat Tube Length | 382 mm | 406 mm | 444 mm | 470 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 210 mm | 230 mm | 250 mm | 265 mm |
| Chainstay Length | 489 mm | 489 mm | 489 mm | 489 mm |
| Wheelbase | 1088 mm | 1110 mm | 1133 mm | 1150 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 617 mm | 617 mm | 673 mm | 674 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 164 cm | 171 cm | 179 cm |
| Rider Max Height | 167 cm | 174 cm | 182 cm | 188 cm |
Model Overview
Stinson E is part of the Marin E Stinson model. 4 e-bikes variations carry this model name so far. You can easily view all of the Marin E Stinson e-bikes models from 2023, here.
Model range prices
Marin Stinson E 2023 is the most affordable e-bike of this model and has a price of 1599$. On the other hand, Marin Stinson E ST 2023, is the most expensive and costs 1599$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, even if your budget is less than the average, you might still be able to get a top-quality Hybrid e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2023 for 1599$. If we compare this with the average Hybrid e-bike cost we notice that the price is 55.1% lower.
Overview of components
Fork material
Stinson E has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the e-bike.
Wheels size
When leaving the production line, the Stinson E model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The Stinson E has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
This e-bike is available in 4 sizes. They vary from 152 cm – 188 cm (4.99 ft – 6.17 ft). In short, you can easily find one that suits you.
