Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Tourney, Altus -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
152cm - 167cm
MD
164cm - 174cm
LG
171cm - 172cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Disc Specific, Low-Step Design, Comfort Control Geometry, Kickstand Mount, Fender and Rack Mounts
Suspension Fork
CrMo Steel, Straight Blade, Disc Specific, Fender and Rack Eyelets
Drivetrain
Rear Derailleur
Shimano Tourney, 7-Speed
Front Derailleur
-
Shift Levers
Shimano Altus 7-Speed RapidFire
Cassette
SunRace 7-Speed, 11-34T
Crank
Alloy Crank, Steel 38T Chainring, Ring Guard
Bottom Bracket
Sealed Cartridge Bearings, Square Taper
Chain
KMC Z8
Pedals
Marin Comfort Platform
Wheels
Front Hub
Forged Aluminum Alloy, 32H
Rear Hub
Forged Aluminum Alloy, 32H
Rims
Marin Aluminum Double Wall, Disc Specific
Tires
Vee Tire Co. Speedster, 27.5”x2.35”, Puncture Protection
Brakes
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin Alloy
Handlebar
Marin Alloy, 60mm Rise, 30? Backsweep
Grips
Marin Adventure
Headset
FSA, TH No.10P
Seat
Saddle
Marin Comfort
Seatpost
Marin Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.85 mm | 1.82 mm | 1.8 mm |
| Bottom Bracket Height | 276.5 mm | 276.5 mm | 276.5 mm |
| Front Center | 608 mm | 630 mm | 652 mm |
| Rake | 40 mm | 40 mm | 40 mm |
| Trail | 87 mm | 87 mm | 87 mm |
| Stack | 627.2 mm | 645.9 mm | 664.5 mm |
| Reach | 339 mm | 354 mm | 369 mm |
| Top Tube Length | 605.7 mm | 628.6 mm | 651.5 mm |
| Seat Tube Angle | 67 ° | 67 ° | 67 ° |
| Seat Tube Length | 382 mm | 406 mm | 444 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 210 mm | 230 mm | 250 mm |
| Chainstay Length | 484 mm | 484 mm | 484 mm |
| Wheelbase | 1082 mm | 1105 mm | 1127 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm |
| Standover Height | 509 mm | 509 mm | 509 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 152 cm | 164 cm | 171 cm |
| Rider Max Height | 167 cm | 174 cm | 172 cm |
About this model
Stinson ST 1 is part of the Marin Stinson model. Marin released 34 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Marin Stinson 1 2021 is the cheapest bike model and costs 569$. Marin Stinson 2 2021 is the most expensive one and costs 679$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Comfort bikes average price
If you want an acceptable Comfort bike you should know that the average price is 360$. However, you could also get a good Comfort bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Marin Stinson ST 1 price was 569$. Comparing this to the average Comfort bike price, we see that the price is 58.06% higher.
Overview of components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
When leaving the production line, the Stinson ST 1 model has aluminum wheels. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Marin Stinson ST 1 is equipped with Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Marin Stinson ST 1 bike has 3 sizes, in the range of 152 cm – 172 cm (4.99 ft – 5.64 ft). In conclusion, you won’t have a problem finding one that suits you.
