Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Fox Float 34
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 4 6061 Aluminum, 29" Wheels, Superlight Aluminum Frame, Flat-Mount Rear Brake, Internal Shifter and Dropper Post Routing, 148x12mm Boost Thru-Axle
Suspension Fork
Fox 34 StepCast, 120mm Travel, Alloy Tapered Steerer, Air Spring, 110x15mm Boost Spacing, Kabolt Thru-Axle, 44mm Offset
Drivetrain
Rear Derailleur
Shimano XT 12-Speed
Front Derailleur
-
Shift Levers
Shimano SLX 12-Speed
Cassette
Shimano SLX 12-Speed, 10-51T
Crank
FSA GRID, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Mego EXO Spindle, Boost Spacing
Bottom Bracket
Mego EXO 73mm BSA
Chain
KMC X12
Pedals
Nylon Platform
Wheels
Front Hub
Shimano, 110x15mm, Centerlock Disc, 32H
Rear Hub
Shimano, 148x12mm, MicroSpline, Centerlock Disc, 32H
Rims
Stan's Flow EX MK3, 29mm Internal, Sleeve Joint, Tubeless Compatible
Tires
Maxxis Rekon Race, 29x2.35", Folding Bead, Tubeless Ready
Brakes
Brake Levers
TRP G-Spec FMR Hydraulic
Cockpit
Stem
Marin 3D Forged Alloy, 35mm
Handlebar
Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 4º Up, 9º Back
Grips
Marin Single Clamp Locking
Headset
FSA No 42ACB, 1 1/8" x 1 1/2”
Seat
Saddle
Marin Speed Concept
Seatpost
TranzX Dropper Post, YSP23 w/ 1x Remote, Size S 125mm Travel, All Other Sizes: 150mm Travel, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.44 mm | 1.39 mm | 1.3 mm |
| Bottom Bracket Height | 319.75 mm | 319.75 mm | 319.75 mm | 319.75 mm |
| Front Center | 704 mm | 726 mm | 748 mm | 786 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 104 mm | 104 mm | 104 mm | 104 mm |
| Stack | 611.9 mm | 616.5 mm | 621.05 mm | 630.3 mm |
| Reach | 408 mm | 428 mm | 448 mm | 483 mm |
| Top Tube Length | 584 mm | 605.3 mm | 626.7 mm | 664.3 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 381 mm | 431 mm | 482 mm | 520 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 97 mm | 102 mm | 107 mm | 117 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1120 mm | 1142 mm | 1164 mm | 1203 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 676 mm | 705 mm | 751 mm | 784 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 169 cm | 177 cm | 184 cm | 190 cm |
Model Overview
Team Marin 2 is part of the Marin Team Marin model. Marin launched 10 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Marin Team Marin 1 2021 is the most affordable bike of this model and has a price of 1469$. On the other hand, Marin Team Marin 2 2021, is the most expensive and costs 2499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2021 and its price was 2499$. In conclusion, this bike price is 10.52% lower than the price of the average Trail bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
This bike has the Fox Float 34 fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork on this bike is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The Team Marin 2 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Marin Team Marin 2 bike has 4 sizes, in the range of 160 cm – 190 cm (5.25 ft – 6.23 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Marin Team Marin 2 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
